**Geometry** (from the Ancient Greek: γεωμετρία; *geo-* "earth", *-metron* "measurement") is a branch of mathematics concerned with questions of shape, size, relative position of figures, and the properties of space.^{[1]} A mathematician who works in the field of geometry is called a geometer.

Geometry arose independently in a number of early cultures as a practical way for dealing with lengths, areas, and volumes.^{[1]} Geometry began to see elements of formal mathematical science emerging in Greek mathematics as early as the 6th century BC.^{[2]} By the 3rd century BC, geometry was put into an axiomatic form by Euclid, whose treatment, Euclid's *Elements*, set a standard for many centuries to follow.^{[3]} Geometry arose independently in India, with texts providing rules for geometric constructions appearing as early as the 3rd century BC.^{[4]} Islamic scientists preserved Greek ideas and expanded on them during the Middle Ages.^{[5]} By the early 17th century, geometry had been put on a solid analytic footing by mathematicians such as René Descartes and Pierre de Fermat. Since then, and into modern times, geometry has expanded into non-Euclidean geometry and manifolds, describing spaces that lie beyond the normal range of human experience.^{[6]}

Geometry has applications to many fields, including art, architecture, physics, as well as to other branches of mathematics.^{[8]}

History

A European and an Arab practicing geometry in the 15th century.

*Woman teaching geometry*. Illustration at the beginning of a medieval translation of Euclid's Elements, (c. 1310)

The earliest recorded beginnings of geometry can be traced to ancient Mesopotamia and Egypt in the 2nd millennium BC.^{[9]}^{[10]} Early geometry was a collection of empirically discovered principles concerning lengths, angles, areas, and volumes, which were developed to meet some practical need in surveying, construction, astronomy, and various crafts. The earliest known texts on geometry are the Egyptian *Rhind Papyrus* (2000–1800 BC) and *Moscow Papyrus* (c. 1890 BC), the Babylonian clay tablets such as Plimpton 322 (1900 BC). For example, the Moscow Papyrus gives a formula for calculating the volume of a truncated pyramid, or frustum.^{[11]} Later clay tablets (350–50 BC) demonstrate that Babylonian astronomers implemented trapezoid procedures for computing Jupiter's position and motion within time-velocity space. These geometric procedures anticipated the Oxford Calculators, including the mean speed theorem, by 14 centuries.^{[12]} South of Egypt the ancient Nubians established a system of geometry including early versions of sun clocks.^{[13]}^{[14]}

In the 7th century BC, the Greek mathematician Thales of Miletus used geometry to solve problems such as calculating the height of pyramids and the distance of ships from the shore. He is credited with the first use of deductive reasoning applied to geometry, by deriving four corollaries to Thales' Theorem.^{[2]} Pythagoras established the Pythagorean School, which is credited with the first proof of the Pythagorean theorem,^{[15]} though the statement of the theorem has a long history.^{[16]}^{[17]} Eudoxus (408–c. 355 BC) developed the method of exhaustion, which allowed the calculation of areas and volumes of curvilinear figures,^{[18]} as well as a theory of ratios that avoided the problem of incommensurable magnitudes, which enabled subsequent geometers to make significant advances. Around 300 BC, geometry was revolutionized by Euclid, whose *Elements*, widely considered the most successful and influential textbook of all time,^{[19]} introduced mathematical rigor through the axiomatic method and is the earliest example of the format still used in mathematics today, that of definition, axiom, theorem, and proof. Although most of the contents of the *Elements* were already known, Euclid arranged them into a single, coherent logical framework.^{[20]} The *Elements* was known to all educated people in the West until the middle of the 20th century and its contents are still taught in geometry classes today.^{[21]} Archimedes (c. 287–212 BC) of Syracuse used the method of exhaustion to calculate the area under the arc of a parabola with the summation of an infinite series, and gave remarkably accurate approximations of Pi.^{[22]} He also studied the spiral bearing his name and obtained formulas for the volumes of surfaces of revolution.

Indian mathematicians also made many important contributions in geometry. The *Satapatha Brahmana* (3rd century BC) contains rules for ritual geometric constructions that are similar to the *Sulba Sutras*.^{[4]} According to (Hayashi 2005, p. 363), the *Śulba Sūtras* contain "the earliest extant verbal expression of the Pythagorean Theorem in the world, although it had already been known to the Old Babylonians. They contain lists of Pythagorean triples,^{[23]} which are particular cases of Diophantine equations.^{[24]}
In the Bakhshali manuscript, there is a handful of geometric problems (including problems about volumes of irregular solids). The Bakhshali manuscript also "employs a decimal place value system with a dot for zero."^{[25]} Aryabhata's *Aryabhatiya* (499) includes the computation of areas and volumes.
Brahmagupta wrote his astronomical work *Brāhma Sphuṭa Siddhānta* in 628. Chapter 12, containing 66 Sanskrit verses, was divided into two sections: "basic operations" (including cube roots, fractions, ratio and proportion, and barter) and "practical mathematics" (including mixture, mathematical series, plane figures, stacking bricks, sawing of timber, and piling of grain).^{[26]} In the latter section, he stated his famous theorem on the diagonals of a cyclic quadrilateral. Chapter 12 also included a formula for the area of a cyclic quadrilateral (a generalization of Heron's formula), as well as a complete description of rational triangles (*i.e.* triangles with rational sides and rational areas).^{[26]}

In the Middle Ages, mathematics in medieval Islam contributed to the development of geometry, especially algebraic geometry.^{[27]}^{[28]} Al-Mahani (b. 853) conceived the idea of reducing geometrical problems such as duplicating the cube to problems in algebra.^{[29]} Thābit ibn Qurra (known as Thebit in Latin) (836–901) dealt with arithmetic operations applied to ratios of geometrical quantities, and contributed to the development of analytic geometry.^{[5]} Omar Khayyám (1048–1131) found geometric solutions to cubic equations.^{[30]} The theorems of Ibn al-Haytham (Alhazen), Omar Khayyam and Nasir al-Din al-Tusi on quadrilaterals, including the Lambert quadrilateral and Saccheri quadrilateral, were early results in hyperbolic geometry, and along with their alternative postulates, such as Playfair's axiom, these works had a considerable influence on the development of non-Euclidean geometry among later European geometers, including Witelo (c. 1230–c. 1314), Gersonides (1288–1344), Alfonso, John Wallis, and Giovanni Girolamo Saccheri.^{[31]}

In the early 17th century, there were two important developments in geometry. The first was the creation of analytic geometry, or geometry with coordinates and equations, by René Descartes (1596–1650) and Pierre de Fermat (1601–1665).^{[32]} This was a necessary precursor to the development of calculus and a precise quantitative science of physics.^{[33]} The second geometric development of this period was the systematic study of projective geometry by Girard Desargues (1591–1661).^{[34]} Projective geometry studies properties of shapes which are unchanged under projections and sections, especially as they relate to artistic perspective.^{[35]}

Two developments in geometry in the 19th century changed the way it had been studied previously.^{[36]} These were the discovery of non-Euclidean geometries by Nikolai Ivanovich Lobachevsky, János Bolyai and Carl Friedrich Gauss and of the formulation of symmetry as the central consideration in the Erlangen Programme of Felix Klein (which generalized the Euclidean and non-Euclidean geometries). Two of the master geometers of the time were Bernhard Riemann (1826–1866), working primarily with tools from mathematical analysis, and introducing the Riemann surface, and Henri Poincaré, the founder of algebraic topology and the geometric theory of dynamical systems. As a consequence of these major changes in the conception of geometry, the concept of "space" became something rich and varied, and the natural background for theories as different as complex analysis and classical mechanics.^{[37]}

Important concepts in geometry

The following are some of the most important concepts in geometry.^{[7]}^{[38]}^{[39]}

Axioms

An illustration of Euclid's parallel postulate

Euclid took an abstract approach to geometry in his Elements,^{[40]} one of the most influential books ever written.^{[41]} Euclid introduced certain axioms, or postulates, expressing primary or self-evident properties of points, lines, and planes.^{[42]} He proceeded to rigorously deduce other properties by mathematical reasoning. The characteristic feature of Euclid's approach to geometry was its rigor, and it has come to be known as *axiomatic* or *synthetic* geometry.^{[43]} At the start of the 19th century, the discovery of non-Euclidean geometries by Nikolai Ivanovich Lobachevsky (1792–1856), János Bolyai (1802–1860), Carl Friedrich Gauss (1777–1855) and others^{[44]} led to a revival of interest in this discipline, and in the 20th century, David Hilbert (1862–1943) employed axiomatic reasoning in an attempt to provide a modern foundation of geometry.^{[45]}

Points

Points are considered fundamental objects in Euclidean geometry. They have been defined in a variety of ways, including Euclid's definition as 'that which has no part'^{[46]} and through the use of algebra or nested sets.^{[47]} In many areas of geometry, such as analytic geometry, differential geometry, and topology, all objects are considered to be built up from points. However, there has been some study of geometry without reference to points.^{[48]}

Lines

Euclid described a line as "breadthless length" which "lies equally with respect to the points on itself".^{[46]} In modern mathematics, given the multitude of geometries, the concept of a line is closely tied to the way the geometry is described. For instance, in analytic geometry, a line in the plane is often defined as the set of points whose coordinates satisfy a given linear equation,^{[49]} but in a more abstract setting, such as incidence geometry, a line may be an independent object, distinct from the set of points which lie on it.^{[50]} In differential geometry, a geodesic is a generalization of the notion of a line to curved spaces.^{[51]}

Planes

A plane is a flat, two-dimensional surface that extends infinitely far.^{[46]} Planes are used in every area of geometry. For instance, planes can be studied as a topological surface without reference to distances or angles;^{[52]} it can be studied as an affine space, where collinearity and ratios can be studied but not distances;^{[53]} it can be studied as the complex plane using techniques of complex analysis;^{[54]} and so on.

Angles

Acute (a), obtuse (b), and straight (c) angles. The acute and obtuse angles are also known as oblique angles.

Euclid defines a plane angle as the inclination to each other, in a plane, of two lines which meet each other, and do not lie straight with respect to each other.^{[46]} In modern terms, an angle is the figure formed by two rays, called the *sides* of the angle, sharing a common endpoint, called the *vertex* of the angle.^{[55]}

In Euclidean geometry, angles are used to study polygons and triangles, as well as forming an object of study in their own right.^{[46]} The study of the angles of a triangle or of angles in a unit circle forms the basis of trigonometry.^{[56]}

In differential geometry and calculus, the angles between plane curves or space curves or surfaces can be calculated using the derivative.^{[57]}^{[58]}

Curves

A curve is a 1-dimensional object that may be straight (like a line) or not; curves in 2-dimensional space are called plane curves and those in 3-dimensional space are called space curves.^{[59]}

In topology, a curve is defined by a function from an interval of the real numbers to another space.^{[52]} In differential geometry, the same definition is used, but the defining function is required to be differentiable ^{[60]} Algebraic geometry studies algebraic curves, which are defined as algebraic varieties of dimension one.^{[61]}

Surfaces

A sphere is a surface that can be defined parametrically (by *x* = *r* sin *θ* cos *φ*, *y* = *r* sin *θ* sin *φ*, *z* = *r* cos *θ*) or implicitly (by *x*2 + *y*2 + *z*2 − *r*2 = 0.)

A surface is a two-dimensional object, such as a sphere or paraboloid.^{[62]} In differential geometry^{[60]} and topology,^{[52]} surfaces are described by two-dimensional 'patches' (or neighborhoods) that are assembled by diffeomorphisms or homeomorphisms, respectively. In algebraic geometry, surfaces are described by polynomial equations.^{[61]}

Manifolds

A manifold is a generalization of the concepts of curve and surface. In topology, a manifold is a topological space where every point has a neighborhood that is homeomorphic to Euclidean space.^{[52]} In differential geometry, a differentiable manifold is a space where each neighborhood is diffeomorphic to Euclidean space.^{[60]}

Manifolds are used extensively in physics, including in general relativity and string theory^{[63]}

Topologies and metrics

Visual checking of the Pythagorean theorem for the (3, 4, 5) triangle as in the Zhoubi Suanjing 500–200 BC. The Pythagorean theorem is a consequence of the Euclidean metric.

A topology is a mathematical structure on a set that tells how elements of the set relate spatially to each other.^{[52]} The best-known examples of topologies come from metrics, which are ways of measuring distances between points.^{[64]} For instance, the Euclidean metric measures the distance between points in the Euclidean plane, while the hyperbolic metric measures the distance in the hyperbolic plane. Other important examples of metrics include the Lorentz metric of special relativity and the semi-Riemannian metrics of general relativity.^{[65]}

Compass and straightedge constructions

Classical geometers paid special attention to constructing geometric objects that had been described in some other way. Classically, the only instruments allowed in geometric constructions are the compass and straightedge. Also, every construction had to be complete in a finite number of steps. However, some problems turned out to be difficult or impossible to solve by these means alone, and ingenious constructions using parabolas and other curves, as well as mechanical devices, were found.

Dimension

The Koch snowflake, with fractal dimension=log4/log3 and topological dimension=1

Where the traditional geometry allowed dimensions 1 (a line), 2 (a plane) and 3 (our ambient world conceived of as three-dimensional space), mathematicians and physicists have used higher dimensions for nearly two centuries.^{[66]} One example of a mathematical use for higher dimensions is the configuration space of a physical system, which has a dimension equal to the system's degrees of freedom. For instance, the configuration of a screw can be described by five coordinates.^{[67]}

In general topology, the concept of dimension has been extended from natural numbers, to infinite dimension (Hilbert spaces, for example) and positive real numbers (in fractal geometry).^{[68]} In algebraic geometry, the dimension of an algebraic variety has received a number of apparently different definitions, which are all equivalent in the most common cases.^{[69]}

Symmetry

A tiling of the hyperbolic plane

The theme of symmetry in geometry is nearly as old as the science of geometry itself. Symmetric shapes such as the circle, regular polygons and platonic solids held deep significance for many ancient philosophers and were investigated in detail before the time of Euclid. Symmetric patterns occur in nature and were artistically rendered in a multitude of forms, including the graphics of M.C. Escher. Nonetheless, it was not until the second half of 19th century that the unifying role of symmetry in foundations of geometry was recognized. Felix Klein's Erlangen program proclaimed that, in a very precise sense, symmetry, expressed via the notion of a transformation group, determines what geometry *is*. Symmetry in classical Euclidean geometry is represented by congruences and rigid motions, whereas in projective geometry an analogous role is played by collineations, geometric transformations that take straight lines into straight lines. However it was in the new geometries of Bolyai and Lobachevsky, Riemann, Clifford and Klein, and Sophus Lie that Klein's idea to 'define a geometry via its symmetry group' proved most influential. Both discrete and continuous symmetries play prominent roles in geometry, the former in topology and geometric group theory, the latter in Lie theory and Riemannian geometry.

A different type of symmetry is the principle of duality in projective geometry (see Duality (projective geometry)) among other fields. This meta-phenomenon can roughly be described as follows: in any theorem, exchange *point* with *plane*, *join* with *meet*, *lies in* with *contains*, and you will get an equally true theorem. A similar and closely related form of duality exists between a vector space and its dual space.

Contemporary geometry

Euclidean geometry

Geometry lessons in the 20th century

Euclidean geometry is geometry in its classical sense.^{[70]} As its models the space of the physical world, it is used in many scientific areas, such as mechanics, astronomy, crystallography,^{[71]} and many technical fields, such as engineering,^{[72]} architecture,^{[73]} geodesy,^{[74]} aerodynamics,^{[75]} and navigation.^{[76]} The mandatory educational curriculum of the majority of nations includes the study of Euclidean concepts such as points, lines, planes, angles, triangles, congruence, similarity, solid figures, circles, and analytic geometry.^{[38]}

Differential geometry

Differential geometry uses techniques of calculus and linear algebra to study problems in geometry. It has applications in physics, including in general relativity.

Differential geometry has been of increasing importance to mathematical physics due to Einstein's general relativity postulation that the universe is curved. Contemporary differential geometry is *intrinsic*, meaning that the spaces it considers are smooth manifolds whose geometric structure is governed by a Riemannian metric, which determines how distances are measured near each point, and not *a priori* parts of some ambient flat Euclidean space.

Non-Euclidean geometry

Differential geometry uses tools from calculus to study problems involving curvature.

In the nearly two thousand years since Euclid, while the range of geometrical questions asked and answered inevitably expanded, the basic understanding of space remained essentially the same. Immanuel Kant argued that there is only one, *absolute*, geometry, which is known to be true *a priori* by an inner faculty of mind: Euclidean geometry was synthetic a priori.^{[77]} This dominant view was overturned by the revolutionary discovery of non-Euclidean geometry in the works of Bolyai, Lobachevsky, and Gauss (who never published his theory). They demonstrated that ordinary Euclidean space is only one possibility for development of geometry. A broad vision of the subject of geometry was then expressed by Riemann in his 1867 inauguration lecture *Über die Hypothesen, welche der Geometrie zu Grunde liegen* (*On the hypotheses on which geometry is based*),^{[78]} published only after his death. Riemann's new idea of space proved crucial in Einstein's general relativity theory, and Riemannian geometry, that considers very general spaces in which the notion of length is defined, is a mainstay of modern geometry.

Topology and geometry

A thickening of the trefoil knot

Topology is the field concerned with the properties of geometric objects that are unchanged by continuous mappings. In practice, this often means dealing with large-scale properties of spaces, such as connectedness and compactness.

The field of topology, which saw massive development in the 20th century, is in a technical sense a type of transformation geometry, in which transformations are homeomorphisms. This has often been expressed in the form of the dictum 'topology is rubber-sheet geometry'. Contemporary geometric topology and differential topology, and particular subfields such as Morse theory, would be counted by most mathematicians as part of geometry. Algebraic topology and general topology have gone their own ways.

Algebraic geometry

Quintic Calabi–Yau threefold

The field of algebraic geometry is the modern incarnation of the Cartesian geometry of co-ordinates. From late 1950s through mid-1970s it had undergone major foundational development, largely due to work of Jean-Pierre Serre and Alexander Grothendieck. This led to the introduction of schemes and greater emphasis on topological methods, including various cohomology theories. One of seven Millennium Prize problems, the Hodge conjecture, is a question in algebraic geometry.

Algebraic geometry studies geometry through the use of multivariate polynomials and other algebraic techniques. It has applications in many areas, including cryptography and string theory.

The study of low-dimensional algebraic varieties, algebraic curves, algebraic surfaces and algebraic varieties of dimension 3 ("algebraic threefolds"), has been far advanced. Gröbner basis theory and real algebraic geometry are among more applied subfields of modern algebraic geometry. Arithmetic geometry is an active field combining algebraic geometry and number theory. Other directions of research involve moduli spaces and complex geometry. Algebro-geometric methods are commonly applied in string and brane theory.

Convex Geometry

Convex geometry investigates convex shapes in the Euclidean space and its more abstract analogues, often using techniques of real analysis. It has close connections to convex analysis, optimization and functional analysis and important applications in number theory.

Discrete Geometry

Discrete geometry is concerned mainly with questions of relative position of simple geometric objects, such as points, lines and circles. It shares many methods and principles with combinatorics.

Geometric group theory is an expanding area of the theory of more general discrete groups, drawing on geometric models and algebraic techniques.

Computational Geometry

Computational geometry deals with algorithms and their implementations for manipulating geometrical objects. Although being a young area of geometry, it has many applications in computer vision, image processing, computer-aided design, medical imaging, etc.

Applications

Geometry has found applications in many fields, some of which are described below.

Art

Mathematics and art are related in a variety of ways. For instance, the theory of perspective showed that there is more to geometry than just the metric properties of figures: perspective is the origin of projective geometry.

Architecture

Mathematics and architecture are related, since, as with other arts, architects use mathematics for several reasons. Apart from the mathematics needed when engineering buildings, architects use geometry: to define the spatial form of a building; from the Pythagoreans of the sixth century BC onwards, to create forms considered harmonious, and thus to lay out buildings and their surroundings according to mathematical, aesthetic and sometimes religious principles; to decorate buildings with mathematical objects such as tessellations; and to meet environmental goals, such as to minimise wind speeds around the bases of tall buildings.

Physics

The 421polytope, orthogonally projected into the E8 Lie group Coxeter plane. Lie groups have several applications in physics.

Modern geometry has many ties to physics as is exemplified by the links between pseudo-Riemannian geometry and general relativity. One of the youngest physical theories, string theory, is also very geometric in flavour.

Other fields of mathematics

The Pythagoreans discovered that the sides of a triangle could have incommensurable lengths.

Geometry has also had a large effect on other areas of mathematics. For instance, the introduction of coordinates by René Descartes and the concurrent developments of algebra marked a new stage for geometry, since geometric figures such as plane curves could now be represented analytically in the form of functions and equations. This played a key role in the emergence of infinitesimal calculus in the 17th century. The subject of geometry was further enriched by the study of the intrinsic structure of geometric objects that originated with Euler and Gauss and led to the creation of topology and differential geometry.

An important area of application is number theory. In ancient Greece the Pythagoreans considered the role of numbers in geometry. However, the discovery of incommensurable lengths, which contradicted their philosophical views, made them abandon abstract numbers in favor of concrete geometric quantities, such as length and area of figures. Since the 19th century, geometry has been used for solving problems in number theory, for example through the geometry of numbers or, more recently, scheme theory, which is used in Wiles's proof of Fermat's Last Theorem.

While the visual nature of geometry makes it initially more accessible than other mathematical areas such as algebra or number theory, geometric language is also used in contexts far removed from its traditional, Euclidean provenance (for example, in fractal geometry and algebraic geometry).^{[79]}

Analytic geometry applies methods of algebra to geometric questions, typically by relating geometric curves to algebraic equations. These ideas played a key role in the development of calculus in the 17th century and led to the discovery of many new properties of plane curves. Modern algebraic geometry considers similar questions on a vastly more abstract level.

Leonhard Euler, in studying problems like the Seven Bridges of Königsberg, considered the most fundamental properties of geometric figures based solely on shape, independent of their metric properties. Euler called this new branch of geometry *geometria situs* (geometry of place), but it is now known as topology. Topology grew out of geometry, but turned into a large independent discipline. It does not differentiate between objects that can be continuously deformed into each other. The objects may nevertheless retain some geometry, as in the case of hyperbolic knots.
