Road
Road
A road is a thoroughfare, route, or way on land between two places that has been paved or otherwise improved to allow travel by foot or some form of conveyance, including a motor vehicle, cart, bicycle, or horse.
Roads consist of one or two roadways (British English: carriageways), each with one or more lanes and any associated sidewalks (British English: pavement) and road verges. There is sometimes a bike path. Other names for roads include parkways, avenues, freeways, tollways, interstates, highways, or primary, secondary, and tertiary local roads.
Definitions
Historically many roads were simply recognizable routes without any formal construction or maintenance.[1]
The Organisation for Economic Co-operation and Development (OECD) defines a road as "a line of communication (travelled way) using a stabilized base other than rails or air strips open to public traffic, primarily for the use of road motor vehicles running on their own wheels", which includes "bridges, tunnels, supporting structures, junctions, crossings, interchanges, and toll roads, but not cycle paths".[2]
The Eurostat, ITF and UNECE Glossary for Transport Statistics Illustrated defines a road as a "Line of communication (travelled way) open to public traffic, primarily for the use of road motor vehicles, using a stabilized base other than rails or air strips. [...] Included are paved roads and other roads with a stabilized base, e.g. gravel roads. Roads also cover streets, bridges, tunnels, supporting structures, junctions, crossings and interchanges. Toll roads are also included. Excluded are dedicated cycle lanes."[3]
The 1968 Vienna Convention on Road Traffic defines a road as the entire surface of any way or street open to public traffic.[4]
United Kingdom
In the United Kingdom The Highway Code details rules for "road users", but there is some ambiguity between the terms highway and road.[7] For the purposes of the English law, Highways Act 1980, which covers England and Wales but not Scotland or Northern Ireland, road is "any length of highway or of any other road to which the public has access, and includes bridges over which a road passes".[8] This includes footpaths, bridleways and cycle tracks, and also road and driveways on private land and many car parks.[7] Vehicle Excise Duty, a road use tax, is payable on some vehicles used on the public road.[7]
The definition of a road depends on the definition of a highway; there is no formal definition for a highway in the relevant Act.
A 1984 ruling said "the land over which a public right of way exists is known as a highway; and although most highways have been made up into roads, and most easements of way exist over footpaths, the presence or absence of a made road has nothing to do with the distinction.[10][11] Another legal view is that while a highway historically included footpaths, bridleways, driftways, etc., it can now be used to mean those ways that allow the movement of motor-vehicles, and the term rights of way can be used to cover the wider usage.[12]
United States
In the United States, laws distinguish between public roads, which are open to public use, and private roads, which are privately controlled.[13]
Maintenance is becoming an increasing problem in the United States.
Between 1997 and 2018, the number of existing roads too bumpy to drive on compared to roads with decent surfaces has increased by 11%, mostly due to potholes that are not being properly addressed.[14]
History
Transfăgărășan called "the best road in the world" by Top Gear[15]
The Porta Rosa, a Greek street dating from the 3rd to 4th century BC in Velia, with a paved surface and gutters
A paved Roman road in Pompeii
Old tractor road over farmland, Ystad, Sweden
The assertion that the first pathways were the trails made by animals has not been universally accepted; in many cases animals do not follow constant paths.[1] Some believe that some roads originated from following animal trails.[16][17] The Icknield Way may examplify this type of road origination, where human and animal both selected the same natural line.[18] By about 10,000 BC human travelers used rough roads/pathways.[1]
The world's oldest known paved road was constructed in Egypt some time between 2600 and 2200 BC.[19]
Stone- paved streets appear in the city of Ur in the Middle East dating back to 4000 BC.[1]
Corduroy roads (log roads) are found dating to 4000 BC in Glastonbury, England.[1]
The Sweet Track, a timber track causeway in England, is one of the oldest engineered roads discovered and the oldest timber trackway discovered in Northern Europe. Built in winter 3807 BC or spring 3806 BC, (tree-ring dating – dendrochronology – enabled very precise dating). It was claimed to be the oldest road in the world[20][21] until the 2009 discovery of a 6,000-year-old trackway in Plumstead, London.[22][23]
Brick-paved streets appeared in India as early as 3000 BC.[1]
c. 1995 BC: an early subdividing of roadways evidenced with sidewalks built in Anatolia.[24]
In 500 BC, Darius I the Great started an extensive road system for the Achaemenid Empire (Persia), including the Royal Road, which was one of the finest highways of its time,[25] connecting Sardis (the westernmost major city of the empire) to Susa. The road remained in use after Roman times. These road systems reached as far east as Bactria and India.[26]
In ancient times, transport by river was far easier and faster than transport by road,[21] especially considering the cost of road construction and the difference in carrying capacity between carts and river barges. A hybrid of road transport and ship transport beginning in about 1740 is the horse-drawn boat in which the horse follows a cleared path along the river bank.[27][28]
From about 312 BC, the Roman Empire built straight[29] strong stone Roman roads throughout Europe and North Africa, in support of its military campaigns. At its peak the Roman Empire was connected by 29 major roads moving out from Rome and covering 78,000 kilometers or 52,964 Roman miles of paved roads.[21]
In the 8th century AD, many roads were built throughout the Arab Empire. The most sophisticated roads were those in Baghdad, which were paved with tar. Tar was derived from petroleum, accessed from oil fields in the region, through the chemical process of destructive distillation.[30]
The Highways Act 1555 in Britain transferred responsibility for maintaining roads from government to local parishes.[21] This resulted in a poor and variable state of roads. To remedy this, the first of the "Turnpike trusts" was established around 1706, to build good roads and collect tolls from passing vehicles. Eventually there were approximately 1,100 trusts in Britain and some 36,800 km (22,870 miles) of engineered roads.[21] The Rebecca Riots in Carmarthenshire and Rhayader from 1839 to 1844 contributed to a Royal Commission that led to the demise of the system in 1844,[31] which coincided with the development of the UK railway system.
In the late-19th century roading engineers began to cater for cyclists by building separate lanes alongside roadways.
Design
Road design is part of highway engineering. Structural road design is designing a road for its environment in order to extend its longevity and reduce maintenance. The Shell pavement design method is used in many countries for the design of new asphalt roadsides.
Terminology
- where a road slopes towards the outside of a bend, increasing the likelihood that vehicles travelling at speed will skid or topple.Usually only a temporary situation during road maintenance.the route of the road, defined as a series of horizontal tangents and curves.All-weather roadUnpaved road that is constructed of a material that does not create mud during rainfall.A street that allows local vehicle traffic, but is prioritized for bicycles and other non-motorized travelan orange globe, lit at night, used to highlight a pedestrian crossingRigid posts that can be arranged in a line to close a road or path to vehicles above a certain widthHighway over which the public have for vehicular and other kinds of traffic, but is used mainly as a footpath or bridlewayRoad that avoids or "bypasses" a built-up area, town, or villageSection of a road with a carrying capacity substantially below that of other sections of the same roadNon-reflective used on roads(or crown)the slope of the downwards away from the centre of the road, so that surface water can flow freely to the edge of the carriageway, or on bends angling of the surface to lean traffic 'into the bend' reducing the chance of a skid.Another name for cross slope or camberPart of the road intended for the movement of road motor vehicles; the parts of the road which form a shoulder for the lower or upper layers of the road surface are not part of the roadway, nor are those parts of the road intended for the circulation of road vehicles which are not self-propelled or for the parking of vehicles.[3]used on roadsSequence of tight serpentine curves (usually an S-shape curve or a bus stop)Road surface composed of a thin layer of crushed stone 'chips' and asphalt emulsion.It seals the surface and protects it from weather, but provides no structural strength.It is cheaper than or concrete.In the United States it is usually only used on low volume rural roadsRoad on the side of a cliff or mountain, with the ground rising on one side and falling away on the otherThe of the pavement, expressed as units of rise per unit of run, or as a percentage(kerb)A raised edge at the side of the.(also kerb extension, bulb-out, nib, elephant ear, curb bulge and blister) measure, intended to slow the speed of traffic and increase driver awareness, particularly in built-up and residential.Part of a carriageway designated for cycles and distinguished from the rest of the carriageway by longitudinal road markings.Mopeds may also be allowed to use a cycle lane.[3]Independent road or part of a road designated for cycles and sign-posted as such.A cycle track is separated from other roads or other parts of the same road by structural means.Mopeds may also be allowed to use the cycle track.[3]cycling-friendly infrastructure integrated into the roadway or in its own right of waya state road or county road that connects rural or agricultural areas to market towns.(literally "fork in the road") Type of where a road splitsLongitudinal slope(UK) Unsurfaced road, may be so infrequently used that vegetation colonises freely, hence 'green'.Many green lanes are ancient routes that have existed for millennia.Prevents vehicles from veering off the road into oncoming traffic, crashing against solid objects or falling from a road.Also called a or.a drainage channel usually at the edge of the road or along a median.(United States)System of Interstate and Defense HighwaysOne of the longitudinal strips into which a carriageway is divisible, whether or not defined by longitudinal road markings, which is wide enough for one moving line of motor
vehicles other than motor cycles.[3]
- (Pullout, pull-off)A paved area beside a where can stop temporarily to let another car pass.the hazard of stone chippings that have come looseOn roads, including, and many, the central reservation (), median (), median strip (North American English and ), neutral ground [Louisiana English] or central nature strip (Australian English): Area that separates opposing of traffic(Europe) (Freeways in the US, Special road in the UK) Road, specially designed and built for motor traffic, which does not serve properties bordering on it, with separate carriageways for traffic in two directions, with no crossings at the same level (road, railway, tramway track, or footpath) and sign-posted as a motorway and is reserved for specific categories of road motor vehicles.[3]A relatively low level route through a range of mountainsOne of a series of numbered markers placed along a road, often at regular intervals, showing the distance to destinations.National HighwayRoad built and maintained by a national authority.The road regarded as a geoconstruction.In the UK the term is and the pavement is a pedestrian walkway alongside the road.Designated point on a road where road marking or other means helps pedestrians cross safely(officiallyPelicon crossing) (UK) a PEdestrian LIght CONtrolled crossing.Highway owned and operated for profit byRoad owned and maintained by a, organization, or company rather than by a governmentthe vertical alignment of a road, expressed as a series of grades, connected by parabolic curves.A much safer design with a corner refuge island, a setback crossing of the pedestrians and, generally between 1.5–7 metres of setback, a forward stop bar, which allows cyclists to stop for a well ahead of motor traffic who must stop behind the crosswalk.Separate signal staging or at least an advance green for cyclists and pedestrians is used to give cyclists and pedestrians no conflicts or a head start over traffic.The design makes a right turn on red, and sometimes left on red depending on the geometry of the intersection in question, possible in many cases, often without stopping.[32]Cyclists ideally have a protected bike lane on separated by a concrete median with splay if possible, and have a protected bike lane width of at least 2 metres if possible (one way).In the Netherlands, most one way cycle paths are at least 2.5 metres wide.[33]Place where anyone has a right to come without being excluded because of conditionsU.S. road that connects rural and agricultural areas toOften assigned to identify a stretch of public roads – often dependent on the, with numbers differentiating between, motorways,, etc.Process to reduce the harm (deaths, injuries, and property damage) that result from vehicle crashes on public roadsPart or all of the road is occupied for work or maintenanceDeviations from a true planar pavement surface, which affects vehicle suspension deflection, dynamic loading,, surface drainage and winter operations.Roughness have wavelengths ranging from 500 mm up to some 40 m. The upper limit may be as high as 350 m when considering motion sickness aspects; motion sickness is generated by motion with down to 0.1 Hz frequency; in an ambulance car driving 35 m/s (126 km/h), waves with up to 350 m will excite motion sickness.a road junction where typically three or more roads are joined by a circular section of road.Traffic 'on the roundabout' has priority over traffic on approach roads, unless indicated otherwise.In countries where traffic drives on the left the roundabout is travelled in a clockwise direction.Also known as anislandin parts of the UK.Cyclists ideally have a protected bike lane on separated by a concrete median with splay if possible, and have a protected bike lane width of at least 2 metres if possible (one way).In the Netherlands, most one way cycle paths are at least 2.5 metres wide.[33](also hard shoulder)A clear, level area to the side of the roadway available for stopping if needed.Road numbered by the, falling below numbered national highways (like ) in the hierarchyora road maintained by the state, including nationally numbered highwaysTrafficPedestrians, ridden or herded animals, vehicles, bicycles, and other conveyances using any road for purposes of travel.[34]Deviations from a true planar pavement surface, which affects the interaction between road and tire.Microtexture have wavelengths below 0.5 mm, Macrotexture below 50 mm and Megatexture below 500 mm.Set of strategies used by and to slow down or reduce motor vehicle traffic, thereby improving safety for pedestrians and and improving the environment for residents(UK) a small raised area used to help define the traffic flow, which may also act as a refuge for pedestrians crossing the carriageway or a location for signs, barriers or lights – a synonym for in some parts of the UKAlso known as a traffic signal, stop light, stop-and-go lights – a signaling device at a road intersection, pedestrian crossing, or other location that assigns right of way to different approaches to an intersection(UK)a pedestrian crossing marked by black and white stripes on the carriageway
Construction
Layers in the construction of a mortarless pavement: A.) Subgrade B.) Subbase C.) Base course D.) Paver base E.) Pavers F.) Fine-grained sand
Surveyor at work with a leveling instrument
Asphalt layer and Hamm road roller
Sub-base layer composed of cement-based material being applied during construction of the M8 motorway in Ireland
Road construction in Myanmar.
Typical pavement strata for a heavily traveled road
In transport engineering, subgrade is the native material underneath a constructed road
- "Roadbed" (from the 'related terms' & ), as well as the term "Road building" redirects here.
Road construction requires the creation of an engineered continuous right-of-way or roadbed, overcoming geographic obstacles and having grades low enough to permit vehicle or foot travel,[35] and may be required to meet standards set by law[36] or official guidelines.[37] The process is often begun with the removal of earth and rock by digging or blasting, construction of embankments, bridges and tunnels, and removal of vegetation (this may involve deforestation) and followed by the laying of pavement material. A variety of road building equipment is employed in road building.[38][39]
After design, approval, planning, legal and environmental considerations have been addressed alignment of the road is set out by a surveyor.[29] The radii and gradient are designed and staked out to best suit the natural ground levels and minimize the amount of cut and fill.[37] Great care is taken to preserve reference Benchmarks [37]
Roads are designed and built for primary use by vehicular and pedestrian traffic. Storm drainage and environmental considerations are a major concern. Erosion and sediment controls are constructed to prevent detrimental effects. Drainage lines are laid with sealed joints in the road easement with runoff coefficients and characteristics adequate for the land zoning and storm water system. Drainage systems must be capable of carrying the ultimate design flow from the upstream catchment with approval for the outfall from the appropriate authority to a watercourse, creek, river or the sea for drainage discharge.[37]
A borrow pit (source for obtaining fill, gravel, and rock) and a water source should be located near or in reasonable distance to the road construction site. Approval from local authorities may be required to draw water or for working (crushing and screening) of materials for construction needs. The topsoil and vegetation is removed from the borrow pit and stockpiled for subsequent rehabilitation of the extraction area. Side slopes in the excavation area not steeper than one vertical to two horizontal for safety reasons.[37]
Old road surfaces, fences, and buildings may need to be removed before construction can begin.
Trees in the road construction area may be marked for retention.
These protected trees should not have the topsoil within the area of the tree's drip line removed and the area should be kept clear of construction material and equipment.
Compensation or replacement may be required if a protected tree is damaged.
Much of the vegetation may be mulched and put aside for use during reinstatement. The topsoil is usually stripped and stockpiled nearby for rehabilitation of newly constructed embankments along the road. Stumps and roots are removed and holes filled as required before the earthwork begins. Final rehabilitation after road construction is completed will include seeding, planting, watering and other activities to reinstate the area to be consistent with the untouched surrounding areas.[37]
Processes during earthwork include excavation, removal of material to spoil, filling, compacting, construction and trimming.
If rock or other unsuitable material is discovered it is removed, moisture content is managed and replaced with standard fill compacted to meet the design requirements (generally 90–95% relative compaction).
Blasting is not frequently used to excavate the roadbed as the intact rock structure forms an ideal road base. When a depression must be filled to come up to the road grade the native bed is compacted after the topsoil has been removed. The fill is made by the "compacted layer method" where a layer of fill is spread then compacted to specifications, under saturated conditions. The process is repeated until the desired grade is reached.[37]
General fill material should be free of organics, meet minimum California bearing ratio (CBR) results and have a low plasticity index. The lower fill generally comprises sand or a sand-rich mixture with fine gravel, which acts as an inhibitor to the growth of plants or other vegetable matter. The compacted fill also serves as lower-stratum drainage. Select second fill (sieved) should be composed of gravel, decomposed rock or broken rock below a specified particle size and be free of large lumps of clay. Sand clay fill may also be used. The roadbed must be "proof rolled" after each layer of fill is compacted. If a roller passes over an area without creating visible deformation or spring the section is deemed to comply.[37]
Geosynthetics such as geotextiles, geogrids and geocells are frequently used in the various pavement layers to improve road quality. These materials and methods are used in low-traffic private roadways as well as public roads and highways.[40] Geosynthetics perform four main functions in roads: separation, reinforcement, filtration and drainage; which increase the pavement performance, reduce construction costs and decrease maintenance.[41]
The completed road way is finished by paving or left with a gravel or other natural surface. The type of road surface is dependent on economic factors and expected usage. Safety improvements such as traffic signs, crash barriers, raised pavement markers and other forms of road surface marking are installed.
According to a May 2009 report by the American Association of State Highway and Transportation Officials (AASHTO) and TRIP – a national transportation research organization – driving on rough roads costs the average American motorist approximately $400 a year in extra vehicle operating costs.
Drivers living in urban areas with populations more than 250,000 are paying upwards of $750 more annually because of accelerated vehicle deterioration, increased maintenance, additional fuel consumption, and tire wear caused by poor road conditions.
When a single carriageway road is converted into dual carriageway by building a second separate carriageway alongside the first, it is usually referred to as duplication,[42] twinning or doubling. The original carriageway is changed from two-way to become one-way, while the new carriageway is one-way in the opposite direction. In the same way as converting railway lines from single track to double track, the new carriageway is not always constructed directly alongside the existing carriageway.
Maintenance
"Road works ahead" sign, typically used in Europe
Line marking in rural India
Like all structures, roads deteriorate over time.
Deterioration is primarily due to accumulated damage from vehicles, however environmental effects such as frost heaves, thermal cracking and oxidation often contribute.[43] According to a series of experiments carried out in the late 1950s, called the AASHO Road Test, it was empirically determined that the effective damage done to the road is roughly proportional to the Fourth power of axle weight.[44] A typical tractor-trailer weighing 80,000 pounds (36.287 t) with 8,000 pounds (3.629 t) on the steer axle and 36,000 pounds (16.329 t) on both of the tandem axle groups is expected to do 7,800 times more damage than a passenger vehicle with 2,000 pounds (0.907 t) on each axle. Potholes on roads are caused by rain damage and vehicle braking or related construction works.
Pavements are designed for an expected service life or design life. In some parts of the United Kingdom the standard design life is 40 years for new bitumen and concrete pavement. Maintenance is considered in the whole life cost of the road with service at 10, 20 and 30 year milestones.[45] Roads can be and are designed for a variety of lives (8-, 15-, 30-, and 60-year designs). When pavement lasts longer than its intended life, it may have been overbuilt, and the original costs may have been too high. When a pavement fails before its intended design life, the owner may have excessive repair and rehabilitation costs. Some asphalt pavements are designed as perpetual pavements with an expected structural life in excess of 50 years.[46]
Many asphalt pavements built over 35 years ago, despite not being specifically designed as a perpetual pavement, have remained in good condition long past their design life.[47] Many concrete pavements built since the 1950s have significantly outlived their intended design lives.[48] Some roads like Chicago, Illinois's "Wacker Drive", a major two-level viaduct in the downtown area, are being rebuilt with a designed service life of 100 years.[49]
Virtually all roads require some form of maintenance before they come to the end of their service life.
Pro-active agencies use pavement management techniques to continually monitor road conditions and schedule preventive maintenance treatments as needed to prolong the lifespan of their roads. Technically advanced agencies monitor the road network surface condition with sophisticated equipment such as laser/inertial Profilometers. These measurements include road curvature, cross slope, asperity, roughness, rutting and texture. Software algorithms use this data to recommend maintenance or new construction.
Maintenance treatments for asphalt concrete generally include thin asphalt overlays, crack sealing, surface rejuvenating, fog sealingfo, micro milling or diamond grinding and surface treatments. Thin surfacing preserves, protects and improves the functional condition of the road while reducing the need for routing maintenance, leading to extended service life without increasing structural capacity.[50]
Older concrete pavements that develop faults can be repaired with a dowel bar retrofit, in which slots are cut in the pavement at each joint, and dowel bars are placed in the slots, which are then filled with concrete patching material. This can extend the life of the concrete pavement for 15 years.[51]
Failure to maintain roads properly can create significant costs to society, in a 2009 report released by the American Association of State Highway and Transportation Officials (US) about 50% of the roads in the US are in bad condition with urban areas worse.
The report estimates that urban drivers pay an average of $746/year on vehicle repairs while the average US motorist pays about $335/year.
In contrast, the average motorist pays about $171/year in road maintenance taxes (based on 600 gallons/year and $0.285/gallon tax).
Slab stabilization
Distress and serviceability loss on concrete roads can be caused by loss of support due to voids beneath the concrete pavement slabs.
The voids usually occur near cracks or joints due to surface water infiltration. The most common causes of voids are pumping, consolidation, subgrade failure and bridge approach failure. Slab stabilization is a non-destructive method of solving this problem and is usually employed with other Concrete Pavement Restoration (CPR) methods including patching and diamond grinding. The technique restores support to concrete slabs by filing small voids that develop underneath the concrete slab at joints, cracks or the pavement edge.
The process consists of pumping a cementitous grout or polyurethane mixture through holes drilled through the slab. The grout can fill small voids beneath the slab and/or sub-base. The grout also displaces free water and helps keep water from saturating and weakening support under the joints and slab edge after stabilization is complete. The three steps for this method after finding the voids are locating and drilling holes, grout injection and post-testing the stabilized slabs.
Slab stabilization does not correct depressions, increase the design structural capacity, stop erosion or eliminate faulting.
It does, however, restore the slab support, therefore, decreasing deflections under the load.
Stabilization should only be performed at joints and cracks where loss of support exists.
Visual inspection is the simplest manner to find voids.
Signs that repair is needed are transverse joint faulting, corner breaks and shoulder drop off and lines at or near joints and cracks.
Deflection testing is another common procedure utilized to locate voids.
It is recommended to do this testing at night as during cooler temperatures, joints open, aggregate interlock diminishes and load deflections are at their highest.
Testing
Ground penetrating radar pulses electromagnetic waves into the pavement and measures and graphically displays the reflected signal. This can reveal voids and other defects.
The epoxy/core test, detects voids by visual and mechanical methods.
It consists of drilling a 25 to 50 millimeter hole through the pavement into the sub-base with a dry-bit roto-hammer. Next, a two-part epoxy is poured into the hole – dyed for visual clarity. Once the epoxy hardens, technicians drill through the hole. If a void is present, the epoxy will stick to the core and provide physical evidence.
Common stabilization materials include pozzolan-cement grout and polyurethane. The requirements for slab stabilization are strength and the ability to flow into or expand to fill small voids. Colloidal mixing equipment is necessary to use the pozzolan-cement grouts. The contractor must place the grout using a positive-displacement injection pump or a non-pulsing progressive cavity pump. A drill is also necessary but it must produce a clean hole with no surface spalling or breakouts. The injection devices must include a grout packer capable of sealing the hole. The injection device must also have a return hose or a fast-control reverse switch, in case workers detect slab movement on the uplift gauge. The uplift beam helps to monitor the slab deflection and has to have sensitive dial gauges.[52][53]
Joint sealing
Also called joint and crack repair, this method's purpose is to minimize infiltration of surface water and incompressible material into the joint system.
Joint sealants are also used to reduce dowel bar corrosion in Concrete Pavement Restoration (CPR) techniques. Successful resealing consists of old sealant removal, shaping and cleaning the reservoir, installing the backer rod and installing the sealant. Sawing, manual removal, plowing and cutting are methods used to remove the old sealant. Saws are used to shape the reservoir. When cleaning the reservoir, no dust, dirt or traces of old sealant should remain. Thus, it is recommended to water wash, sand-blast and then air blow to remove any sand, dirt or dust. The backer rod installation requires a double-wheeled, steel roller to insert the rod to the desired depth. After inserting the backer rod, the sealant is placed into the joint. There are various materials to choose for this method including hot pour bituminous liquid, silicone and preformed compression seals.[52][54][55][56]
Safety considerations
Pedestrian crossing, line markings and street furniture.
Careful design and construction of roads can increase road traffic safety and reduce the harm (deaths, injuries, and property damage) on the highway system from traffic collisions.
On neighborhood roads traffic calming, safety barriers, pedestrian crossings and cycle lanes can help protect pedestrians, cyclists, and drivers.
Lane markers in some countries and states are marked with Cat's eyes or |Botts dots, bright reflectors that do not fade like paint. Botts dots are not used where it is icy in the winter, because frost and snowplows can break the glue that holds them to the road, although they can be embedded in short, shallow trenches carved in the roadway, as is done in the mountainous regions of California.
For major roads risk can be reduced by providing limited access from properties and local roads, grade separated junctions and median dividers between opposite-direction traffic to reduce likelihood of head-on collisions.
The placement of energy attenuation devices (e.g. guardrails, wide grassy areas, sand barrels) is also common.
Some road fixtures such as road signs and fire hydrants are designed to collapse on impact. Light poles are designed to break at the base rather than violently stop a car that hits them. Highway authorities may also remove larger trees from the immediate vicinity of the road. During heavy rains, if the elevation of the road surface isn't higher than the surrounding landscape, it may result in flooding.[57]
Speed limits can improve road traffic safety and reduce the number of road traffic casualties from traffic collisions. In their World report on road traffic injury prevention report, the World Health Organization (WHO) identify speed control as one of various interventions likely to contribute to a reduction in road casualties.
Road conditions
Road conditions are the collection of factors describing the ease of driving on a particular stretch of road, or on the roads of a particular locality, including the quality of the pavement surface, potholes, road markings, and weather. It has been reported that "[p]roblems of transportation participants and road conditions are the main factors that lead to road traffic accidents".[58]*Icctp%202011%3A%20Toward]]*t has further been specifically noted that "weather conditions and road conditions are interlinked as weather conditions affect the road conditions".autonomous vehicles self-driving cars conditions can include "shadowing and lighting changes, road surface texture changes, and road markings consisting of circular reflectors, dashed lines, and solid lines".[60]
Various government agencies and private entities, including local news services, track and report on road conditions to the public, so that drivers going through a particular area can be aware of hazards that may exist in that area.
News agencies, in turn, rely on tips from area residents with respect to certain aspects of road conditions in their coverage area.[61]
Environmental performance
Air pollution along Pasadena Highway in Los Angeles
Road after rain
The A22(T) with line markings near Summer Hill, East Sussex, England
Road with guard rails in Kaluga Oblast, Russia
Road with traffic signs in the outskirts of Bern, Switzerland
NH 73 going to Bangalore
Ontario Highway 401, a route with a collector / express setup
The wide Coastal Road in the Philippines now called the Manila-Cavite Expressway
Road in Jujuy Province, Argentina
Careful design and construction of a road can reduce any negative environmental impacts.
Water management systems can be used to reduce the effect of pollutants from roads.[62][63] Rainwater and snowmelt running off of roads tends to pick up gasoline, motor oil, heavy metals, trash and other pollutants and result in water pollution. Road runoff is a major source of nickel, copper, zinc, cadmium, lead and polycyclic aromatic hydrocarbons (PAHs), which are created as combustion byproducts of gasoline and other fossil fuels.[64]
Roads are a chief source of noise pollution. In the early 1970s it was recognized that design of roads can be conducted to influence and minimize noise generation.[67] Noise barriers can reduce noise pollution near built-up areas. Regulations can restrict the use of engine braking.
Motor vehicle emissions contribute air pollution. Concentrations of air pollutants and adverse respiratory health effects are greater near the road than at some distance away from the road.[68] Road dust kicked up by vehicles may trigger allergic reactions.[69] In addition, on-road transportation greenhouse gas emissions are the largest single cause of climate change, scientists say.[70]
Regulation
Right- and left-hand traffic
Traffic flows on the right or on the left side of the road depending on the country.[71] In countries where traffic flows on the right, traffic signs are mostly on the right side of the road, roundabouts and traffic circles go counter-clockwise/anti-clockwise, and pedestrians crossing a two-way road should watch out for traffic from the left first.[72] In countries where traffic flows on the left, the reverse is true.
Economics
A city street in Mumbai, India with left-hand traffic
Transport economics is used to understand both the relationship between the transport system and the wider economy and the complex network effects when there are multiple paths and competing modes for both personal and freight (road/rail/air/ferry) and where Induced demand can result in increased on decreased transport levels when road provision is increased by building new roads or decreased (for example California State Route 480). Roads are generally built and maintained by the public sector using taxation although implementation may be through private contractors).[75][76] or occasionally using road tolls.[77]
Public-private partnerships are a way for communities to address the rising cost by injecting private funds into the infrastructure. There are four main ones:[78]
design/build
design/build/operate/maintain
design/build/finance/operate
build/own/operate
Society depends heavily on efficient roads.
In the European Union (EU) 44% of all goods are moved by trucks over roads and 85% of all people are transported by cars, buses or coaches on roads.[79] The term was also commonly used to refer to roadsteads, waterways that lent themselves to use by shipping.
Construction costs
According to the New York State Thruway Authority,[80] some sample per-mile costs to construct multi-lane roads in several US northeastern states were:
Connecticut Turnpike – $3,449,000 per mile
New Jersey Turnpike – $2,200,000 per mile
Pennsylvania Turnpike (Delaware Extension) – $1,970,000 per mile
Northern Indiana Toll Road – $1,790,000 per mile
Garden State Parkway – $1,720,000 per mile
Massachusetts Turnpike – $1,600,000 per mile
Thruway, New York to Pennsylvania Line – $1,547,000 per mile
Ohio Turnpike – $1,352,000 per mile
Pennsylvania Turnpike (early construction) – $736,000 per mile
Statistics
The United States has the largest network of roads of any country with 4,050,717 miles (6,518,997 km) as of 2009.[81] The Republic of India has the second largest road system in the world with 4,689,842 kilometres (2,914,133 mi) of road (2013).[82] The People's Republic of China is third with 3,583,715 kilometres (2,226,817 mi) of road (2007). The Federative Republic of Brazil has the fourth largest road system in the world with 1,751,868 kilometres (1,088,560 mi) (2002). See List of countries by road network size. When looking only at expressways the National Trunk Highway System (NTHS) in China has a total length of 45,000 kilometres (28,000 mi) at the end of 2006, and 60,300 km at the end of 2008, second only to the United States with 90,000 kilometres (56,000 mi) in 2005. However, as of 2017 China has 130,000 km of Expressways.[83][84]
Global connectivity
Eurasia, Africa, North America, South America, and Australia each have an extensive road network that connects most cities.
The North and South American road networks are separated by the Darién Gap, the only interruption in the Pan-American Highway. Eurasia and Africa are connected by roads on the Sinai Peninsula. The European Peninsula is connected to the Scandinavian Peninsula by the Øresund Bridge, and both have many connections to the mainland of Eurasia, including the bridges over the Bosphorus. Antarctica has very few roads and no continent-bridging network, though there are a few ice roads between bases, such as the South Pole Traverse. Bahrain is the only island country to be connected to a continental network by road (the King Fahd Causeway to Saudi Arabia). Even well-connected road networks are controlled by many different legal jurisdictions, and laws such as which side of the road to drive on vary accordingly.
Many populated domestic islands are connected to the mainland by bridges.
A very long example is the 113 mi (182 km) Overseas Highway connecting many of the Florida Keys with the continental United States.
Even on mainlands, some settlements have no roads connecting with the primary continental network, due to natural obstacles like mountains or wetlands, remoteness, or general expense.
Unpaved roads or lack of roads are more common in developing countries, and these can become impassible in wet conditions. As of 2014, only 43% of rural Africans have access to an all-season road.[85] Due to steepness, mud, snow, or fords, roads can sometimes be passable only to four-wheel drive vehicles, those with snow chains or snow tires, or those capable of deep wading or amphibious operation.
Cities on the mainland of continents which do not have road access include:
Iquitos, Peru, population 437,376 (2015) in the Amazon rainforest
Juneau, Alaska, population 32,406 (2014)
Nome, Alaska, population 3,788 (2014)
Rankin Inlet, Nunavut, population 2,577 (2011)
Supai, Arizona, population 208 (2010) in the Grand Canyon
Most disconnected settlements have local road networks connecting ports, buildings, and other points of interest.
Where demand for travel by road vehicle to a disconnected island or mainland settlement is high, roll-on/roll-off ferries are commonly available if the journey is relatively short. For long-distance trips, passengers usually travel by air and rent a car upon arrival. If facilities are available, vehicles and cargo can also be shipped to many disconnected settlements by boat, or air transport at much greater expense. The island of Great Britain is connected to the European road network by Eurotunnel Shuttle – an example of a car shuttle train which is a service used in other parts of Europe to travel under mountains and over wetlands.
In polar areas, disconnected settlements are often more easily reached by snowmobile or dogsled in cold weather, which can produce sea ice that blocks ports, and bad weather that prevents flying. For example, resupply aircraft are only flown to Amundsen–Scott South Pole Station October to February, and many residents of coastal Alaska have bulk cargo shipped in only during the warmer months. Permanent darkness during the winter can also make long-distance travel more dangerous in polar areas. Continental road networks do reach into these areas, such as the Dalton Highway to the North Slope of Alaska, the R21 highway to Murmansk in Russia, and many roads in Scandinavia (though due to fjords water transport is sometimes faster). Large areas of Alaska, Canada, Greenland, and Siberia are sparsely connected. For example, all 25 communities of Nunavut are disconnected from each other and the main North American road network.[86]
Road transport of people and cargo by may also be obstructed by border controls and travel restrictions. For example, travel from other parts of Asia to South Korea would require passage through the hostile country of North Korea. Moving between most countries in Africa and Eurasia would require passing through Egypt and Israel, which is a politically sensitive area.
Some places are intentionally car-free, and roads (if present) might be used by bicycles or pedestrians.
Roads are under construction to many remote places, such as the villages of the Annapurna Circuit, and a road was completed in 2013 to Mêdog County. Additional intercontinental and transoceanic fixed links have been proposed, including a Bering Strait crossing that would connect Eurasia-Africa and North America, a Malacca Strait Bridge to the largest island of Indonesia from Asia, and a Strait of Gibraltar crossing to connect Europe and Africa directly.
