T-64

T-64

The T-64 is a Soviet second-generation main battle tank introduced in the early 1960s. It was a more advanced counterpart to the T-62: the T-64 served tank divisions, while the T-62 supported infantry in motorized rifle divisions. It introduced a number of advanced features including composite armor, a compact engine and transmission, and a smoothbore 125-mm gun equipped with an autoloader to allow the crew to be reduced to three so the tank could be smaller and lighter. In spite of being armed and armored like a heavy tank, the T-64 weighed only 38 tonnes (42 short tons; 37 long tons).

These features made the T-64 expensive to build, significantly higher than previous generations of Soviet tanks. This was especially true of the power pack, which was time-consuming to build and cost twice as much as more conventional designs. Several proposals were made to improve the T-64 with new engines, but chief designer Alexander Morozov's political power in Moscow kept the design in production in spite of any concerns about price. This led to the T-72 being designed as an emergency design, only to be produced in the case of a war, but its 40% lower price led to it entering production in spite of Morozov's objections.

At present the T-64 is in use in very few nations or regions, but is currently undergoing significant factory overhauls and modernization in Ukraine. The newest, vastly upgraded and improved model of this 50-year-old design, the T-64BM Bulat, has increased in weight to 45 tonnes and is seeing active service in the field.

T-64
TypeMain battle tank
Place of originSoviet Union
Service history
In service1964–present
Used bySee Operators
Wars
  • War of Transnistria
  • War in Donbass
Production history
DesignerKMDB
Designed1951–1962
ManufacturerMalyshev Factory
Produced1963–1987
No. built≈13,000
Specifications (T-64A[2])
Mass38 tonnes (42 short tons; 37 long tons)
Length9.225 m (30 ft 3.2 in) (gun forward)
Width3.415 m (11 ft 2.4 in)
Height2.172 m (7 ft 1.5 in)
Crew3 (driver, commander, gunner)

ArmourGlass-reinforced plastic sandwiched between layers of steel. ERA plates optional Hull & turret –
370 mm to 440 mm vs APFSDS
500 mm to 575 mm vs HEAT[1]
Main
armament
D-81T (aka 2A46)125 mm smoothbore gun
Secondary
armament
7.62 mm PKMT coaxial machine gun, 12.7 mm NSVT anti-aircraft machine gun
Engine5TDF 5-cylinder diesel
700 hp (522 kW)
Power/weight18.4 hp/tonne (13.7 kW/ton)
SuspensionTorsion bar
Operational
range
500 km (310 mi), 700 km (430 mi) with external tanks
Speed45–60 km/h (28–37 mph) depending on version

Overview

The T-64 was conceived at the Kharkiv Morozov Machine Building Design Bureau in Ukraine (Ukrainian SSR), as the next-generation main battle tank by Alexander A. Morozov, the designer of the T-54 (which, in the meantime, would be incrementally improved by Leonid N. Kartsev's Nizhny Tagil bureau, by the models T-54A, T-54B, T-55, and T-55A).

A revolutionary feature of the T-64 is the incorporation of an automatic loader for its 125-mm gun, allowing one crew member's position to be omitted and helping to keep the size and weight of the tank down. Tank troopers would joke that the designers had finally caught up with their unofficial hymn, Three Tankers—the song had been written to commemorate the crewmen fighting in the Battle of Khalkhin Gol, in 3-man BT-5 tanks in 1939.[3]

The T-64 also pioneered other Soviet tank technology: the T-64A model of 1967 introduced the 125-mm smooth-bore gun, and the T-64B of 1976 would be able to fire an anti-tank guided missile through its gun barrel.

The T-64 design was used as basis by LKZ for the gas turbine-powered T-80 main battle tank. The T-64A turret was adopted for early T-80 tank models, with its main gun and automatic loading mechanism, and upgraded armour.

The T-64 would only be used by the Soviet Army and never exported, unlike the T-54/55. The tank equipped elite and regular formations in Eastern Europe and elsewhere, the T-64A model being first deployed with East Germany's Group of Soviet Forces in Germany (GSFG) in 1976, and some time later in Hungary's Southern Group of Forces (SFG). By 1981, the improved T-64B began to be deployed in East Germany and later in Hungary. While it was believed that the T-64 was reserved for elite units, it was also used by much lower level "non-ready formations", for example, the Odessa Military District's 14th Army.

With the break-up of the Soviet Union in 1991, T-64 tanks remained in the arsenals of Russia, Ukraine, Belarus and Uzbekistan. Mid 2014, slightly fewer than 2,000 of the former Soviet inventory of T-64 tanks are in service with the military of Ukraine and about 4,000 are out-of-service and awaiting destruction in Russia.[4]

Development history

Object 430

Object 430 prototype on display at the Kubinka Tank Museum in September 2008

Object 430 prototype on display at the Kubinka Tank Museum in September 2008

Studies for the design of a new battle tank started as early as 1951. The KB-60M team was formed at the Kharkiv design bureau of the Kharkiv transport machine-building factory No. 75 named for Malyshev (Russian: конструкторское бюро Харьковского завода транспортного машиностроения №75 им. Малышева) by engineers coming back from Nizhniy Tagil, with Morozov at its head.

A project named obyekt 430 gave birth to three prototypes which were tested in Kubinka in 1958.[5] Those vehicles showed characteristics that were going to radically change the design of battle tanks on this side of the Iron Curtain. For the first time, an extremely compact opposed-piston engine was used: the 4TD, designed by the plant's engine design team. The transmission system comprised two lateral gears on each side of the engine. Those two innovations yielded a very short engine compartment with the opening located beneath the turret. The engine compartment volume was almost half that of the T-54. An improved cooling system and a new lightweight suspension was fitted, featuring hollow metallic wheels of a small diameter and caterpillar tracks with rubber joints.

The tank would be armed with the D-54TS and frontal armour of 120 mm. As it did not present a clear superiority in terms of combat characteristics when compared to the T-55, which was entering active service, Morozov decided that production was not yet ready given the project's drawbacks. However, studies conducted on the obyekt 430U, featuring a 122 mm gun and 160 mm of armour, demonstrated that the tank had the potential to fit the firepower and armour of a heavy tank on to a medium tank chassis. A new project was consequently started, obyekt 432.

Object 432

The gun fitted on this new tank was a powerful 115 mm D-68 (2A21). This was a potentially risky decision to replace the human loader by an electro-hydraulic automatic system, since the technology was new to Russian designers. The crew was reduced to three, which allowed a considerable reduction in internal volume and external visible silhouette, and consequently in weight, from 36 tonnes (obyekt 430) to 30.5 tonnes. The height dropped by 76 mm.

However, the arrival of the British 105 mm L7 gun and the US M68 variant of it, fitted to the Centurion and M60 tanks, forced the team to undertake another audacious première, with the adoption of composite armour. The recently created process was called "K combination" by Western armies: this protection consisted of an aluminium alloy layer between two high strength steel layers. As a consequence, the weight of the prototype rose eventually to 34 tonnes. But, as the engine was now a 700 hp (515 kW) 5TDF (also locally designed), its mobility remained excellent, far superior to that the T-62. The obyekt 432 was ready in September 1962 and production started in October 1963 in the Kharkiv plant. On 30 December 1966, it entered service as the T-64.

T-64A

Obyekt 447 at the Museum of the Great Patriotic War, Kiev, Ukraine

Obyekt 447 at the Museum of the Great Patriotic War, Kiev, Ukraine

The T-64 has a characteristic exhaust vent in the rear

The T-64 has a characteristic exhaust vent in the rear

T-64AK at the T-34 Tank History Museum in Russia

T-64AK at the T-34 Tank History Museum in Russia

Even as the first T-64s were rolling off the assembly lines, the design team was working on a new version, named object 434, which would allow it to maintain firepower superiority. The brand new and very powerful 125 mm D-81T gun, from the Perm weapons factory, was fitted to the tank. This gun was merely a scaled-up version of the 115 mm smoothbore cannon from the T-62. The larger size of the 125 mm ammunition meant that less could be carried inside the T-64, and with a fourth crewman loader taking up space as well, the tank would only have a 25-round capacity. This was unacceptably low for the Soviet designers, but strict dimensional parameters forbade them from enlarging the tank to increase interior space. The solution was to replace the human loader with a mechanical autoloader, cutting the crew to three and marking the first use of autoloaders in a Soviet MBT.[6] The 6ETs10 autoloader has 28 rounds and can fire 8 shots per minute; the stabiliser, a 2E23, was coupled to the new TPD-2-1 (1G15-1) sight. Night driving was also adapted with the new TPN-1-43A periscope, which would benefit from the illumination of a powerful infrared L2G projector, fitted on the left side of the gun. The shielding was improved, with fibreglass replacing the aluminium alloy in the armour, and small spring-mounted plates fitted along the mudguards (known as the Gill skirt), to cover the top of the suspension and the side tanks. They were, however, extremely fragile and were often removed. Some small storage spaces were created along the turret, with a compartment on the right and three boxes on the front left. Snorkels were mounted on the rear of the turret. A NBC protection system was fitted and the hatches were widened.

Prototypes were tested in 1966 and 1967 and, as production began after the six hundredth T-64, it entered service in the Soviet Army under the designation T-64A. Chief engineer Morozov was awarded the Lenin Prize for this model's success.

Designed for elite troops, the T-64A was constantly updated as available equipment was improved. After only three years in service, a first modernisation occurred, regarding:

  • fire control, by replacing the sights with the TPD-2-49 day sight with an optical coincidence rangefinder and a TPN-1-49-23 night sight, and stabilisation by mounting a 2E26 system.

  • the radio by mounting a R-123M

  • night vision with a TBN-4PA for the driver and a TNP-165A for the tank leader. His battlepost was transformed by mounting a small stabilised turret with an anti-aircraft NSVT 12.7 mm × 108 machine gun, electrically guided through an optical PZU-5 sight, and fed with 300 rounds. It could be used from within the tank so that the tank leader could avoid being exposed (as on previous tanks). The possibility of mounting a KMT-6 anti-mine system was also added.

A derived version appeared at the same time, designed for the commanding officer and named T-64AK. It comprised a R-130M radio with a 10 m telescopic antenna, which could be used only in a static position as it required shrouds, an artillery aiming circle PAB-2AM and TNA-3 navigation station; all of these could be powered by an auxiliary gasoline-fired generator.

In 1976, the weapons system was improved by mounting a D-81TM (2A46-1), stabilised by a 2E28M2, supplied by an automatic 6ETs10M. The night sight was replaced by a TNPA-65 and the engine could accept different fuels, including diesel fuel, kerosene or gasoline. The production, first carried on the B variant, stopped in 1980.

The majority of T-64As were further modernised after 1981, by mounting a six smoke grenade-launcher 81 mm 902A on each side of the gun, and by replacing the gill plates by a rubber skirt for a longer life. Some of them seem to have been fitted with reactive bricks (as the T-64AV) after 1985, or even with laser TPD-K1 telemeters instead of the optical TPD-2-49 optical coincidence rangefinder (1981). Almost all T-64s were modernised into T-64R, between 1977 and 1981, by reorganising external storage and snorkels, similar to the T-64A.

T-64B

The design team was carrying on its work on new versions. Problems with the setup of the 5TDF engine occurred as the local production capacity was proven to be insufficient against a production done in three factories (Malyshev in Kharkiv, Kirov in Leningrad and Uralvagonzavod).

From 1961, an alternative to the obyekt 432 was studied, with 12 V-cylinder V-45 engine: the obyekt 436. Three prototypes were tested in 1966 in the Chelyabinsk factory. The order to develop a model derived from the 434 with the same engine gave the obyekt 438, later renamed as obyekt 439. Four tanks of this type were built and tested in 1969, which showed the same mobility as the production version, but mass production was not started. They served however as a basis for the design of the T-72 engine compartment.

At the beginning of the 1970s, the design team was trying to improve the tank further. The T-64A-2M study in 1973, with its more powerful engine and its reinforced turret, served as a basis for two projects:

  • Obyekt 476 with a 6TD 1000 hp (735 kW) engine which served as a model for the T-80 combat compartment.

  • Obyekt 447 which featured a new fire control with a laser telemeter, and which was able to fire missiles through the gun.

For the latter, the order was given to start its production under the name T-64B, as well as a derived version (which shared 95% of its components), the obyekt 437, without the missile guidance system for cost reasons. The latter was almost twice as much produced under the designation T-64B1. On 3 September 1976, the T-64B and the T-64B1 were declared good for the service, featuring the improved D-81Tm gun (2A46-2) with a 2E26M stabiliser, a 6ETs40 loader and a 1A33 fire control, including:

  • a 1V517 ballistic calculator

  • a 1G21 sight with laser telemetry

  • a 1B11 cross-wind sensor.

Its ford capacity reaches 1.8 m without equipment. The T-64B had the ability to fire the new 9M112 "Kobra" radio-guided missile (NATO code "AT-8 Songster"). The vehicle then carries 8 missiles and 28 shells. The missile control system is mounted in front of the tank leader small turret and has many changes. The T-64B1 carries only 37 shells and has 2,000 7.62 mm rounds, against 1,250 for the T-64B.

They were modernised in 1981 by the replacement of the gun by a 2A46M1, the stabiliser by a 2E42, and the mounting of a 902A "Tucha-1" smoke grenade launcher in two groups of four, on each side of the gun. Two command versions are realised, very similar to the T-64AK: the T-64BK and the T-64B1K.

The decision, in October 1979, to start production of the 6TD engine, and its great similarity with the 5TDF engine, allowed after some study to fit it in versions B and B1, but also A and AK, yielding the new models T-64AM, T-64AKM, T-64BM and T-64BAM, entering service in 1983.

The production ended in 1987 for all versions. The total production has reached almost 13,000.

Modernisations in Ukraine

Ukrainian T-64BM Bulat on parade

Ukrainian T-64BM Bulat on parade

T-64BV model 2017 during a rehearsal for the Independence Day parade in Kyiv, August 2018. This version is recognizable by the absence of an infrared searchlight on the left of the main gun.

T-64BV model 2017 during a rehearsal for the Independence Day parade in Kyiv, August 2018. This version is recognizable by the absence of an infrared searchlight on the left of the main gun.

After the dissolution of the USSR, Ukraine carried on the development of T-64 modernization, as the original and main factory was in this country. Two different upgrade packages were developed in 1999[7]

  • T-64BM2, with a 57DFM 850-hp (625 kW) engine, a new 1A43U fire control, a new 6ETs43 loader and the possibility to fire the 9M119 missile (NATO code "AT-11 Sniper").

  • T-64U which integrated on top the 1A45 fire control (from the T-80U and T-84), PNK-4SU and TKN-4S optics for the tank commander and PZU-7 for the AA machine gun. The tank leader is then able to drive the tank and to use the gun directly if needed. Kontakt-5 Armor added few prototypes build.

The two variants are also protected by Kontakt-5 modular reactive armour, able to resist to kinetic energy projectiles, as opposed to the first models which were efficient only against HEAT shaped-charge ammunition. Those two variants could also be re-motorised with the 6TDF 1,000 hp (735 kW) engine.

  • T-64BM BULAT Ukrainian army on use modernization, incorporating Nizh (Knife) reactive armor that offers better performance dealing with tandem warheads than the Russian Kontakt-5, new Ukrainian-made 125 mm KBA3 gun, TO1-KO1ER night sight and capability of firing the Ukrainian Kombat tandem-warhead anti-tank guided missile.

In 2010, the Kharkiv Malyshev Factory upgraded ten T-64B tanks (originally produced in Kharkiv in 1980) to T-64BM Bulat standard, and a further nineteen were delivered in 2011. These twenty-nine tanks are being upgraded under a ₴200 million ($25.1M) contract signed in April 2009. As of October 2011, the Ukrainian Army has 76 T-64BM Bulat in service. According to Malyshev Factory chief engineer Konstantin Isyak, the T-64BM Bulat is armoured to the level of modern tanks. It has Nizh (Knife) reactive armour, and Varta active protection system. The Bulat weighs 45 tonnes (44 long tons), and with its 850 hp (630 kW) 5TDFM multi-fuel diesel engine can travel at 70 km/h (43 mph), with a range of 385 km (239 mi). It retains the 125 mm smoothbore gun with an autoloader for 28 rounds, some of which can be guided missiles. It has a 12.7 mm AA machinegun, and a 7.62 mm coaxial machinegun.[8][9] A 2019 refurbishing program upgraded the fire-control system to model 1A43U and uprated the engine.[10]

  • T-64BV model 2017

In 2019, UkrOboronProm reported that the Kharkiv Armored Plant (KhBTZ) had delivered over 100 updated tanks to the Ukrainian Armed Forces.[11] The upgraded tanks included new thermal imaging for all crew, remove Luna infrared searchlight, include TPN-1-TPV Ukrainian night sight in place of TPN1-49-23, Nizh reactive armour modules designed for bolt-on replacement on T-64BV turrets, SN-4215 networked satellite navigation unit, and Lybid K-2RB digital radio (under licence from Motorola) providing secure communications with a 70 km range.[12] Russian defense reporter and expert Alexey Khlopotov claims the tank is superior to the Russian upgraded T-72B3 due to above-mentioned devices.[13] In August 2019, UkrOboronProm announced the Lviv Armored Plant (LBTZ) had also started modernizing T-64s to the 2017 standard [14]

Production history

Different sources differ on the initial production date of the tank that is set between 1963 and 1967. However it is normally agreed that the T-64 formally entered service with the army in 1967 and was publicly revealed in 1970.[15][16] The T-64 was KMDB's high-technology offering, intended to replace the IS-3 and T-10 heavy tanks in independent tank battalions. Meanwhile, the T-72 was intended to supersede the T-55 and T-62 in equipping the bulk of the Soviet tank and mechanized forces, as well as for export partners and east-block satellite states.

It introduced a new autoloader, which is still used on all T-64s currently in service, as well as all variants of the T-80 except the Ukrainian T-84-120. The T-64 prototypes had the same 115 mm smoothbore gun as the T-62, the ones put in full-scale production had the 125 mm gun.

While the T-64 was the superior tank, it was more expensive and physically complex, and was produced in smaller numbers. The T-72 is mechanically simpler and easier to service in the field, while it is not as well protected, and its manufacturing process is correspondingly simpler. In light of Soviet doctrine, the superior T-64s were kept ready and reserved for the most important mission: a potential outbreak of a war in Europe.

In Soviet times, T-64 was mostly in service with units stationed in East Germany opposing the Chieftain-equipped units of the BAOR. No T-64s were exported. Many T-64s ended up in Russian and Ukrainian service after the breakup of the Soviet Union.

Models

  • Ob'yekt 430 (1957) – Prototype with D-10T 100-mm gun, 120 mm armour, 4TPD 580 hp (427 kW) engine, 36 tonnes.

  • Ob'yekt 430U – Project, equipped with a 122-mm gun and 160 mm of armour.

  • T-64 or Ob'yekt 432 (1961) – Prototype with a D-68 115-mm gun, then initial production version with the same features, about 600 tanks produced.

  • T-64R (remontirniy, rebuilt)[17] or Ob'yekt 432R – Redesigned between 1977 and 1981 with external gear from the T-64A but still with the 115-mm gun. T-64 upgraded to T-64A standard. Preserving the 115 mm gun is questionable.

  • T-64A or Ob'yekt 434 – 125-mm gun, "gill" armour skirts, a modified sight, and suspension on the fourth road wheel.

  • T-64T (1963) – Experimental version with a GTD-3TL 700 hp (515 kW) gas turbine.

  • Ob'yekt 436 – Alternative version of Ob'yekt 432 with a V-45 engine. Three built.

  • Ob'yekt 438 and Ob'yekt 439 – Ob'yekt 434 with V-45 diesel engine.

  • T-64AK or Ob'yekt 446 (1972) – Command version, with a R-130M radio and its 10 m (33 ft) telescoping antenna, a TNA-3 navigation system, without antiaircraft machine gun, carrying 38 rounds of main gun ammunition.

  • Ob'yekt 447 – Prototype of the T-64B. Basically a T-64A fitted with the 9K112 "Kobra" system and a1G21 gunsight. This is the "T-64A" displayed in the Kiev museum.

  • T-64B or Ob'yekt 447A (1976) – Fitted with redesigned armour, 1A33 fire control system, 9K112-1 "Kobra" ATGM system (NATO code "AT-8 Songster"), TPN-1-49-23 sight, 2A46-2 gun, 2E26M stabiliser and 6ETs40 loader. Later B/BV models have more modern systems 1A33-1, TPN-3-49, 2E42 and a 2A46M-1 gun. From 1985 the T-64B was fitted with stronger glacis armour; older tanks were upgraded with a 16-mm armour plate. Tanks, equipped with the 1,000 hp 6DT engine are known as T-64BM.

  • T-64BV – Features "Kontakt-1" reactive armour and "Tucha" 81-mm smoke grenade launchers on the left of the turret.

  • T-64BM2 or Ob'yekt 447AM-2 – "Kontakt-5" reactive armour, rubber protection skirts, 1A43U fire control, 6ETs43 loader and able to fire the 9K119 missile (NATO code "AT-11A Sniper"), 5TDFM 850 hp (625 kW) engine.

  • T-64U, BM Bulat, or Ob'yekt 447AM-1 – Ukrainian modernisation, bringing the T-64B to the standard of the T-84. Fitted with Nizh reactive armour, 9K120 Refleks missile (NATO code AT-11 Sniper), 1A45 Irtysh fire control, TKN-4S commander's sight, PZU-7 antiaircraft machine-gun sight, TPN-4E Buran-E night vision, 6TDF 1,000-hp (735 kW) engine. T-64U is one of 2 variants of the modernization program in 1990s, while Bulat is the most recent modernization from 2004.

  • T-64B1 or Ob'yekt 437 – Same as the B without the fire control system and "Kobra", carrying 37 shells.

  • T-64B1M – T-64B1 equipped with the 1,000-hp 6DT engine, redesigned turret and improved armor. Modernization program from 1970s (resulted in T-64AM, AKM, BM and B1M; note that BM is not the same as T-64BM "Bulat" from 2004). Never entered mass production.

  • T-64BK and T-64B1K or Ob'yekt 446B – Command versions, with an R-130M radio and its 10-m telescoping antenna, a TNA-3 navigation system and AB-1P/30 APU, without antiaircraft machine gun, carrying 28 shells.

  • Obyekt 476 – Five prototypes with the 6TDF engine, prototypes for T-80UD development.

  • BREM-64 or Ob'yekt 447T – Armoured recovery vehicle with a light 2.5-tonne crane, dozer blade, tow bars, welding equipment, etc. Only a small number was built.

  • T-55-64 – Heavily upgraded T-55 with the complete hull and chassis of the T-64, fitted with "Kontakt-1" ERA. Prototype.

  • T-Rex - Ukrainian T-64 concept with unmanned turret, intended to counter the new Russian T-14 Armata MBT.[18]

Modernisations

T-64

  • 1977–1981 – brought to the T-64R standard, reorganisation of external equipment as on the T-64A.

T-64A/AK

  • 1972 redesign, fire control improvement (TPD-2-49 and TPN-1-49-23), inclusion of the NSVT machine gun on an electrical turret, R-123M radio.

  • 1973 redesigned turret with improved armor protection.

  • 1975 redesign, new 2E28M stabiliser, 6ETs10M loader, multi-fuel engine, 2A46-1 gun and TNPA-65 night vision.

  • 1979 introduced smoke grenade launchers "Tucha".

  • 1980 rubber skirts on the suspension instead of the Gill protection.

  • 1981 redesign, two sets of six 902A smoke grenade launchers.

  • 1983 T-64AM,T-64AKM, some tanks were equipped with the 6TDF engine during maintenance.

  • 1985 installation of ERA "Kontakt-1" during overhaul. Upgraded tanks designated T-64AV. Due to ERA installation, "Tucha" was repositioned from the front of the turret to the left side.

T-64B/B1/BK/B1K

  • 1979 introduced smoke grenade launchers "Tucha".

  • 1980 rubber skirts on the suspension instead of the Gill protection.

  • 1981 redesign, 2 sets of four 902B2 smoke grenade launchers (in fact this is related to the ERA installation since 1985), 2A26M1 gun.

  • 1983 T-64BM,T-64B1M,T-64BMK and T-64B1MK: some tanks were equipped with the 6TDF engine during maintenance.

  • 1985 T-64BV,T-64BV1,T-64BVK and T-64BV1K: with "Kontakt-1" reactive armour, smoke grenade launchers on the left of the turret.

  • BM Bulat – T-64 modernization by the Malyshev Factory in Ukraine (see above).[8][9]

  • 2011 T-64E

  • 2017 T-64BV type 2017: Night sight TPN1-49-23 replaced with TPN-1-TPV from Trimen-Ukraine, added СН-4215 satellite navigation system from Orizon-Navihatsiia, new Lybid-K 2RB digital radio, Luna infrared searchlight removed, and improved reactive armour units.[19][20][21] This upgrade for T-64BV tanks was received by the 14th Mechanized Brigade, participated in Strong Europe Tank Challenge 2017, and over a hundred of these was in service by 2019.[22]

Variants

BAT-2 combat engineering vehicle

BAT-2 combat engineering vehicle

  • BMPV-64 – Heavy infantry fighting vehicle, based on the chassis of the T-64 but with a completely redesigned hull with a single entry hatch in the rear. Armament consists of a remote-controlled 30mm autocannon and 7.62mm machine gun. Combat weight is 34.5 tons. The first prototype was ready in 2005.[23][24]

  • BTRV-64 – Similar APC version.[24]

  • UMBP-64 – Modified version that will serve as the basis for several (planned) specialized vehicles, including a fire support vehicle, an ambulance and an air-defence vehicle.

  • BMPT-K-64 – This variant is not tracked but has a new suspension with 4 axles, similar to the Soviet BTR series. The vehicle is powered by a 5TDF-A/700 engine and has a combat weight of 17.7 tons. It is fitted with a RCWS and can transport 3+8 men. Prototype only.

  • BAT-2 – Fast combat engineering vehicle with the engine, lower hull and "small roadwheels" suspension of the T-64.[25] The 40-ton tractor sports a very large, all axis adjustable V-shaped hydraulic dozer blade at the front, a single soil ripper spike at the rear and a 2-ton crane on the top. The crew compartment holds 8 persons (driver, commander, radio operators plus a five-man sapper squad for dismounted tasks). The highly capable BAT-2 was designed to replace the old T-54/AT-T based BAT-M, but Warsaw Pact allies received only small numbers due to its high price and the old and new vehicles served alongside during the late Cold War.

  • UMR-64 – Ukrainian development using surplus T-64s to create a Heavy APC/IFV design, which in turn is intended as the basis of a new family of combat and support vehicles. The basic conversion includes moving the engine compartment forward, and at the same time removing the turret and normal crew compartment. This allows the installation of any one of 15 different 'functional modules', weighing up to 22 tons. One resulting option is the Heavy IFV, designated BMP-64E, which combines accommodation for up to 10 troops (not including the driver) with a remote weapons system. The Heavy APC version is designated the BTR-64E, and can not only carry more troops (at the cost of the RWS) but comes with large armoured double hatches at the rear for rapid loading and disembarkation. Other options include a universal supplies carrier (UMBP-64), a 'highly secure command and staff car with a weight up to 41 tons', and a 120 mm mortar carrier. The Kharkiv Armor Repair Plant (Zavod 311) is behind the project.[26] Current status of the program is unclear as of early 2014.

Service history

Cold War

A Soviet T-64 of the 21st Motor Rifle Division in Perleberg, East Germany, in the 1980s.

A Soviet T-64 of the 21st Motor Rifle Division in Perleberg, East Germany, in the 1980s.

According to David Isby, the T-64 entered service in 1967 with the 41st Guards Tank Division in the Kiev Military District,[27] the suggestion being that this was prudent due to the proximity of the division to the factory, and significant teething problems during induction into service that required constant presence of factory support personnel with the division during acceptance and initial crew and service personnel training on the new type. It appears that the tank remained secret to the West for some years between its entry into production in the first half of 1960s and the official acceptance in the Soviet Army in 1967.

The T-64A began deployment to the Soviet Union's western military districts during the 1970s, and was gradually deployed to first line units in the Group of Soviet Forces in Germany in East Germany and Soviet troops in neighboring Warsaw Pact states. The first GSFG unit to receive the T-64A was the 14th Guards Motor Rifle Division at Jüterbog, which became the 32nd Guards Tank Division in 1982. When NATO detected the new tank after it was first deployed to East Germany, it was initially misidentified as the T-72. The T-64 mainly served with Soviet tank units in northern East Germany that were part of the 2nd Guards Tank Army, the 3rd Army, and the 20th Guards Army, although it began to be phased out and replaced by the newer T-80BV/T80U before Soviet troops were withdrawn from Germany in the late 1980s and early 1990s. However, when the Soviet troops withdrew from Germany, two divisions and the 6th Separate Guards Motor Rifle Brigade still operated the T-64.[28]

In September 1990, the Soviet Union had 3,982 T-64s in service west of the Urals, with 2,091 of these in Ukraine. 1,386 of these were T-64As, 220 T-64AKs, 1,192 T-64Bs, 159 T-64BVs, 420 T-64B1s, 27 T-64B1K/BV1K, and 578 T-64Rs.[28] During the Soviet period, the T-64 was never exported.[29]

It is normally reported that the T-64 was not used in the Soviet–Afghan War since the 40th Soviet Army that was deployed there used T-54/55 and T-62 tanks, possibly due to the limited use of tanks in mountain warfare. A small number of T-64 tanks were tested in Afghanistan[30] during January 1980, but were quickly withdrawn without seeing combat because their engines did not perform well in the high altitude necessary for Afghan operations.[29]

Post-Soviet period

A Ukrainian T-64 in the Donbass, August 2014

A Ukrainian T-64 in the Donbass, August 2014

Ukrainian Army T-64BM during a training exercise

Ukrainian Army T-64BM during a training exercise

After the dissolution of the Soviet Union in 1991, the new Russian Ground Forces decided to standardize the tank fleet with the T-72 and the T-80, and the T-64s were gradually put in reserve or scrapped.[28]

In June 1992, 18 Russian-manned T-64BV tanks from the Odessa Military District's 59th Guards Motor Rifle Division were taken over by the Transnistrian Army, fighting in the Transnistria War. Two T-64s were disabled during by Moldovan Ground Forces troops near Bender during Russian counterattacks,[31] one of which was knocked out by an MT-12 100mm anti-tank gun. These actions were the first combat use of the tank.[29]

While Russian T-80 tanks participated in the First Chechen War, any use of T-64 in Chechnya is not clearly documented, but it is possible in limited numbers.

The T-64 was finally used in large scale combat in mid 2014 during the War in Donbass, with the Ukrainian Army deploying T-64 tanks as the main battle tank in the offensive against pro-Russian separatists. Also, towards the end of August 2014, over 20 T-64 tanks were documented as being operated by Military forces of Novorossiya.[32] Ukrainian and NATO officials claimed that these T-64s were supplied to the separatists by Russia.[33] By the end of August 2014, over 70 T-64 tanks of various configurations, including at least three T-64 BM Bulat tanks, were documented as destroyed[34] in the war in Donbass.

The subsidiary of the State Company Ukrspecexport, the State Company Ukroboronservice, concluded the foreign economic contract for major overhaul and supply of 50 main battle tanks T64BV-1. The works will be performed by the State Enterprise Kharkiv plant of armored tanks.[35][36]

Capabilities and limitations

The T-64 did not share many of the drawbacks of the T-72, even if it is often confused with it:

  • The automatic loader is hydraulic, not electric, thus is much faster (loading cycle of 6 to 13 seconds), more reliable, and less sensitive to jolting when running off-road. It also has a "sequence" fire mode that feeds the gun with shells of the same type in less than five seconds. It is also able, in the modern versions, to turn backwards to keep a good speed at the end of the loading sequence.

  • Driving seems much less exhausting for the crew, thanks to assisted controls and a more flexible suspension.[37]

  • The ammunition is stowed at the lower point of the turret shaft, minimizing the risks of destruction by self-detonation.

  • The tank commander's cupola provides good vision, the antiaircraft machine gun can be operated from inside the turret; the commander can also control the main gun sight if necessary.

Additionally, the adoption of the autoloader was highly controversial for several reasons:

  • Early versions of the autoloader lacked safety features and were dangerous to the tank crews (especially the gunner, who sits nearby): Limbs could be easily caught in the machinery, leading to injuries and deaths. A sleeve unknowingly snagged on one of the autoloader's moving parts could also drag a crewman into the apparatus upon firing.[6]

  • Powder charges were stored separately from the shells in a vertical position, presenting much larger surface for a potential hit. Moreover, due to the lower placement of the autoloader's carousel and T-64 smaller roadwheels, the charges were covered only by the thin side armor, without the benefit of the roadwheels or the side skirts for additional protection.

  • The turret was poorly configured to allow the crew to manually load the gun should the autoloader break. In such situations, rate of fire usually slowed to an abysmal one round per minute as the gunner fumbles with the awkward task of working around the broken machine to load the gun.[6]

  • While having smaller tank crews (three vs. the usual four) is advantageous since more tanks can theoretically be fielded using the same number of soldiers, there are also serious downsides. Tanks require frequent maintenance and refueling, and much of this is physically demanding work that several people must work together to accomplish. Most of the time, these duties are also performed at the end of a long day of operations, when everyone in the tank is exhausted. Having one less crewman for these tasks increases the strain on the remaining three men and increases the frequency of botched or skipped maintenance. This problem worsens if the tank's commander is also an officer who must often perform other duties such as higher-level meetings, leaving only two men to attend to the tank.[38] All of this means that tanks with three-man crews are more likely to suffer from performance-degrading human exhaustion, and mechanical failures that take longer to fix and that keep the tank from reaching the battlefield. These problems are exacerbated during prolonged time periods of operations.

The T-64 was furthermore criticized for being too mechanically complex, which resulted in a high breakdown rate.

  • One of the worst problem was the suspension system, featuring an entirely new and advanced design. Due to these problems, teams of civilian mechanics from the T-64 factories were "semi-permanent residents" of Soviet tank units early in the T64's initial adoption phase.[39]

  • The 5TDF opposed-piston engine, while powerful and compact, was very finicky and prone to malfunctions and fires. Russian expert Viktor Murakhovsky, then a battalion commander in Group of Soviet Forces in Germany reflected that in his unit the rate of the engines requiring a major overhaul was close to one per tank in a year. He also noted the difficulty of starting this engine, especially in the damp German winters, and that starting aids used by soldiers, like the high-pressure air and/or oil injection, often led to the engine fires.

Operators

Current operators

  • Democratic Republic of the Congo – 25 T-64BV-1 tanks received from Ukraine in 2016.[40][41]

  • [[INLINE_IMAGE|//upload.wikimedia.org/wikipedia/commons/thumb/5/58/Flag_of_Transnistria.svg/23px-Flag_of_Transnistria.svg.png|//upload.wikimedia.org/wikipedia/commons/thumb/5/58/Flag_of_Transnistria.svg/35px-Flag_of_Transnistria.svg.png 1.5x, //upload.wikimedia.org/wikipedia/commons/thumb/5/58/Flag_of_Transnistria.svg/46px-Flag_of_Transnistria.svg.png 2x|Transnistria|h12|w23|thumbborder flagicon-img flagicon-img]] Transnistria – 18 T-64BVs are in service.

  • Ukraine – 2,345 were in service as of 1995, 2,277 as of 2000 and 2,215 as of 2005.[42] Currently, around 600 are in service, 900+ in storage and over 100 from those that are in active service are modernized to T-64BM Bulat. [[INLINE_IMAGE|//upload.wikimedia.org/wikipedia/commons/thumb/f/fc/Flag_of_Donetsk_People%27s_Republic.svg/23px-Flag_of_Donetsk_People%27s_Republic.svg.png|//upload.wikimedia.org/wikipedia/commons/thumb/f/fc/Flag_of_Donetsk_People%27s_Republic.svg/35px-Flag_of_Donetsk_People%27s_Republic.svg.png 1.5x, //upload.wikimedia.org/wikipedia/commons/thumb/f/fc/Flag_of_Donetsk_People%27s_Republic.svg/45px-Flag_of_Donetsk_People%27s_Republic.svg.png 2x|Donetsk People's Republic|h15|w23|thumbborder flagicon-img flagicon-img]] Donetsk People's Republic – multiple T-64B, T-64BV and T-64BM in service as of 2017.[43] [[INLINE_IMAGE|//upload.wikimedia.org/wikipedia/commons/thumb/7/7b/Flag_of_Lugansk_People%27s_Republic.svg/23px-Flag_of_Lugansk_People%27s_Republic.svg.png|//upload.wikimedia.org/wikipedia/commons/thumb/7/7b/Flag_of_Lugansk_People%27s_Republic.svg/35px-Flag_of_Lugansk_People%27s_Republic.svg.png 1.5x, //upload.wikimedia.org/wikipedia/commons/thumb/7/7b/Flag_of_Lugansk_People%27s_Republic.svg/45px-Flag_of_Lugansk_People%27s_Republic.svg.png 2x|Luhansk People's Republic|h15|w23|thumbborder flagicon-img flagicon-img]] Luhansk People's Republic – multiple T-64B, T-64BV and T-64BM in service as of 2017.[43]

  • Uzbekistan – 100 in service as of 2017.[44]

Former operators

T-64BV technical information

Dimensions

  • Length (gun to the front): 9.225 m[48]

  • Length (without the gun): 6.54 m

  • Breadth: 3.6 m[48]

  • Height: 2.17 m[48]

  • Weight: 42.5 t[48]

Crew

Three men:

  • commander

  • driver

  • gunner

Propulsion

  • Engine: 5TDF multifuel (diesel, kerosene and petrol) with 5 opposed cylinders, 10 piston, 13.6 L. Developing 700 hp (515 kW) at 2,800 rpm, consumption of 170 to 200 litres per 100 km.

  • Transmission: two lateral gearboxes with seven forward and one backward gear.

  • Three internal tanks for a 740 litres fuel capacity, two on the mudguards with 140 litres and two droppable 200 litres tanks on the aft end of the chassis.

Performance

  • Max. road speed: 60.5 km/h.

  • Max off-road speed: 35 km/h.

  • Power-to-weight ratio: 16.2 hp/t (11.9 kW/t).

  • Range: 500 km, 700 km with additional tanks.

  • Ground pressure: 0.9 kgf/cm2 (88 kPa, 12.8 psi).

  • Able to ford in 1.8 m of water without preparation and 5 m with snorkels.

  • Crosses a 2.8 m wide trench.

  • Crosses a 0.8 m high obstacle.

  • Max. slope 30°.

Armament

  • 125 mm smoothbore 2A46M-1 gun (D-81TM) with carousel 6ETs40 loader, 28 shots, fire rate 8 shots per minute, 36 embedded shots (8 x 9M112M "Kobra" (NATO code "AT-8 Songster"), 28 shells). Available shells are all fin-stabilised: anti-personnel (APERS) version of the 3UOF-36, 3OVF-22, with several perforating abilities. armour-piercing shells (APFSDS) 3UBM-17 or 3UBM-19 or older ones with a supplementary charge giving them an initial speed of about 1800 m/s. hollow charge shells, 3VUK-25 or 3UBK-21.

  • coaxial machine gun 7.62 mm PKT with 1,250 rounds.

  • remote-controlled air-defence machine gun 12.7 mm NSVT "Utyos" with 300 rounds.

  • 4+4 (T-64B) or 6+6 (T-64A) 81 mm smoke mortars 902B "Tucha-2".

Equipment

  • The 1A33 fire control system, with: Radio control of the 9K112 "Kobra" missiles (NATO code "AT-8 Songster") launched from the gun. The 2E28M hydraulic stabiliser (vertical range −5°20' to +15°15') The gunner day sight 1G42 with embedded laser telemeter. The TPN-1-49-23 active IR night sight. The L2G IR projector left of the gun for illumination. The 1V517 ballistic calculator. The 1B11 anemometric gauge.

  • The tank commander's cupola is equipped with: The PKN-4S combined day and night sight which allows a 360° vision and to fire the main weapons. The PZU-6 AA sight. The 2Z20 2-axis electrical stabiliser (vertical range −3° to +70°).

  • The TPN-3-49 or TPN-4 and TVN-4 night vision for the driver.

  • A R-173M radio.

  • An CBRN protection, with radiation detectors and global compartment overpressure.

  • Two snorkels for crossing rivers with a depth up to 5 m.

  • A KMT-6 mine clearing plough can be fitted at the front.

Protection

  • 3-layer composite armour (K formula), with a thickness between 450 and 20 mm: Front: 120 mm steel, 105 mm glass fibre, 40 mm steel. Sides: 80 mm steel. Front of the turret: 150 mm steel, 150 mm glass fibre, 40 mm steel

  • Lateral rubber skirts protecting the top of the suspension.

  • Kontakt-1 reactive bricks covering: The front and the side of the turret The glacis The lateral skirts

See also

  • List of tanks

  • List of Soviet tanks

  • T-80

  • T-90

  • T-95

  • 125 mm Smoothbore Rounds

Tanks of comparable role and era

  • Chieftain tank: Approximate British equivalent

References

[1]
Citation Linkweb.archive.orgSoviet Tank Programs Archived 2015-09-24 at the Wayback Machine page 12 published by the CIA under the Freedom of Information Act
Sep 29, 2019, 3:43 AM
[2]
Citation Linkweb.archive.orgT-64A Main Battle Tank Archived 2015-02-09 at the Wayback Machine Kharkiv Morozov Machine Building
Sep 29, 2019, 3:43 AM
[3]
Citation Linkweb.archive.orgТри танкиста Archived 2011-07-19 at the Wayback Machine (Three Tankers)
Sep 29, 2019, 3:43 AM
[4]
Citation Linkweb.archive.orgAdrian Croft (14 June 2014). "NATO says images raise suspicions that Russia moved tanks into Ukraine". Reuters. Archived from the original on 14 June 2014. Retrieved 14 June 2014. phased out of service and were slated for destruction
Sep 29, 2019, 3:43 AM
[5]
Citation Linkwww.meshwar.vistcom.ru"Archived copy". Archived from the original on 2009-09-19. Retrieved 2010-04-22.CS1 maint: archived copy as title (link) Main battle tank T-64 (Основной боевой танк Т-64)
Sep 29, 2019, 3:43 AM
[6]
Citation Linkopenlibrary.orgPerrett 1987:42
Sep 29, 2019, 3:43 AM
[7]
Citation Linkwww.morozov.com.ua"KMDB - Armoured Vehicle Upgrade Projects". morozov.com.ua. Archived from the original on 14 May 2011. Retrieved 25 October 2014.
Sep 29, 2019, 3:43 AM
[8]
Citation Linkweb.archive.orgwknews.ru Украинская армия получила десять модернизированных Т-64, 28 October 2010 Archived 7 November 2010 at the Wayback Machine
Sep 29, 2019, 3:43 AM
[9]
Citation Linkwww.morozov.com.ua"Kharkiv Morozov Machine Building Design Bureau Main Characteristics of the Upgraded BM Bulat Battle Tank". Archived from the original on 19 October 2004. Retrieved 15 November 2014.
Sep 29, 2019, 3:43 AM
[10]
Citation Linkukroboronprom.com.ua"'Завод імені Малишева' відновив чергову партію 'Булатів' для українського війська" [Malyshev Factory refurbished the next batch of Bulats for the Ukrainian army]. UkrOboronProm (in Ukrainian). 2019-05-03. Retrieved 2019-07-22.
Sep 29, 2019, 3:43 AM
[11]
Citation Linkukroboronprom.com.ua"Модернізований Т-64 зразка 2017 року від ДП "Харківський бронетанковий завод" - нові бойові можливості серійної бойової машини" [Modernized T-64 Model 2017 from DP Kharkiv Armour Factory: New Combat Capabilities of a Serial-Production Fighting Vehicle]. UkrOboronProm (in Ukrainian). 2019-02-11. Retrieved 2019-07-22.
Sep 29, 2019, 3:43 AM
[12]
Citation Linkweb.archive.org"UkrOboronProm unveils improved version of T-64 tank". Defence Blog. 2019-02-11. Archived from the original on 2019-03-06. Retrieved 2019-03-03.
Sep 29, 2019, 3:43 AM
[13]
Citation Linkweb.archive.org"Russian expert says about Ukrainian T-64 tank superiority over T-72B3 – media". Unian. 2019-02-15. Archived from the original on 2019-02-24. Retrieved 2019-03-03.
Sep 29, 2019, 3:43 AM
[14]
Citation Linkwww.ukrmilitary.comhttps://www.ukrmilitary.com/2019/08/t64-mod2017.html
Sep 29, 2019, 3:43 AM
[15]
Citation Linkweb.archive.orgARG. "T-64 Main Battle Tank | Military-Today.com". military-today.com. Archived from the original on 17 October 2014. Retrieved 25 October 2014.
Sep 29, 2019, 3:43 AM
[16]
Citation Linkweb.archive.org"T64 Tank". fas.org. Archived from the original on 19 October 2014. Retrieved 25 October 2014.
Sep 29, 2019, 3:43 AM
[17]
Citation Linkopenlibrary.orgSewell, Stephen, CW2 (rtd). "Why Three Tanks?" (Armor, July–August 1998), p. 45.
Sep 29, 2019, 3:43 AM
[18]
Citation Linkweb.archive.orgAdministrator. "Ukraine to develop the T-Rex a new main battle tank to compete the Russian T-14 Armata MBT 12301171 - January 2017 Global Defense Security army news industry - Defense Security global news industry army 2017 - Archive News year". www.armyrecognition.com. Archived from the original on 12 April 2018. Retrieved 9 May 2018.
Sep 29, 2019, 3:43 AM
[19]
Citation Linkweb.archive.org"Нова модернізація Т-64 пройде Хрещатиком" [A new T-64 modernization will parade on Khreshchatyk]. MIL.IN.UA (in Ukrainian). 2018-08-20. Archived from the original on 2019-04-14. Retrieved 2019-04-14.
Sep 29, 2019, 3:43 AM
[20]
Citation Linkweb.archive.org"Модернізація танку Т-64БВ з тепловійзійним прицілом, GPS навігацією та іншими опціями почала надходити до Збройних Сил України" [T-64BV tank modernization with thermal-vision sight, GPS navigation, and other options began deliveries to the Ukrainian Armed Forces]. MIL.IN.UA (in Ukrainian). 2017-05-02. Archived from the original on 2019-01-18. Retrieved 2019-04-14.
Sep 29, 2019, 3:43 AM
