# Dijkstra's algorithm

# Dijkstra's algorithm

Class | Search algorithm |
---|---|

Data structure | Graph |

Worst-case performance |

**Dijkstra's algorithm** (or **Dijkstra's Shortest Path First algorithm**, **SPF algorithm**)^{[1]} is an algorithm for finding the shortest paths between nodes in a graph, which may represent, for example, road networks. It was conceived by computer scientist Edsger W. Dijkstra in 1956 and published three years later.^{[2]}^{[3]}^{[4]}

The algorithm exists in many variants. Dijkstra's original algorithm found the shortest path between two given nodes,^{[4]} but a more common variant fixes a single node as the "source" node and finds shortest paths from the source to all other nodes in the graph, producing a shortest-path tree.

For a given source node in the graph, the algorithm finds the shortest path between that node and every other.^{[5]} ^{[]} It can also be used for finding the shortest paths from a single node to a single destination node by stopping the algorithm once the shortest path to the destination node has been determined. For example, if the nodes of the graph represent cities and edge path costs represent driving distances between pairs of cities connected by a direct road (for simplicity, ignore red lights, stop signs, toll roads and other obstructions), Dijkstra's algorithm can be used to find the shortest route between one city and all other cities. A widely used application of shortest path algorithm is network routing protocols, most notably IS-IS (Intermediate System to Intermediate System) and Open Shortest Path First (OSPF). It is also employed as a subroutine in other algorithms such as Johnson's.

The Dijkstra algorithm uses labels that are positive integers or real numbers, which are totally ordered. It can be generalized to use any labels that are partially ordered, provided the subsequent labels (a subsequent label is produced when traversing an edge) are monotonically non-decreasing. This generalization is called the Generic Dijkstra shortest-path algorithm.^{[6]}

`Dijkstra's algorithm uses a data structure for storing and querying partial solutions sorted by distance from the start. The original algorithm uses amin-priority queueand runs intime(whereis the number of nodes). The idea of this algorithm is also given inLeyzorek et al. 1957.Fredman & Tarjan 1984propose using aFibonacci heapmin-priority queue to optimize the running time complexity to(whereis the number of edges). This isasymptoticallythe fastest known single-sourceshortest-path algorithmfor arbitrarydirected graphswith unbounded non-negative weights. However, specialized cases (such as bounded/integer weights, directed acyclic graphs etc.) can indeed be improved further as detailed inSpecialized variants.`

In some fields, artificial intelligence in particular, Dijkstra's algorithm or a variant of it is known as **uniform cost search** and formulated as an instance of the more general idea of best-first search.^{[7]}

Class | Search algorithm |
---|---|

Data structure | Graph |

Worst-case performance |

History

What is the shortest way to travel from Rotterdam to Groningen, in general: from given city to given city. It is the algorithm for the shortest path, which I designed in about twenty minutes. One morning I was shopping in Amsterdam with my young fiancée, and tired, we sat down on the café terrace to drink a cup of coffee and I was just thinking about whether I could do this, and I then designed the algorithm for the shortest path. As I said, it was a twenty-minute invention. In fact, it was published in ’59, three years later. The publication is still readable, it is, in fact, quite nice. One of the reasons that it is so nice was that I designed it without pencil and paper. I learned later that one of the advantages of designing without pencil and paper is that you are almost forced to avoid all avoidable complexities. Eventually that algorithm became, to my great amazement, one of the cornerstones of my fame.— Edsger Dijkstra, in an interview with Philip L. Frana, Communications of the ACM, 2001

^{[3]}

Dijkstra thought about the shortest path problem when working at the Mathematical Center in Amsterdam in 1956 as a programmer to demonstrate the capabilities of a new computer called ARMAC.^{[8]} His objective was to choose both a problem and a solution (that would be produced by computer) that non-computing people could understand. He designed the shortest path algorithm and later implemented it for ARMAC for a slightly simplified transportation map of 64 cities in the Netherlands (64, so that 6 bits would be sufficient to encode the city number).^{[3]} A year later, he came across another problem from hardware engineers working on the institute's next computer: minimize the amount of wire needed to connect the pins on the back panel of the machine. As a solution, he re-discovered the algorithm known as Prim's minimal spanning tree algorithm (known earlier to Jarník, and also rediscovered by Prim).^{[9]}^{[10]} Dijkstra published the algorithm in 1959, two years after Prim and 29 years after Jarník.^{[11]}^{[12]}

Algorithm

Illustration of Dijkstra's algorithm finding a path from a start node (lower left, red) to a goal node (upper right, green) in a robot motion planning problem. Open nodes represent the "tentative" set (aka set of "unvisited" nodes). Filled nodes are visited ones, with color representing the distance: the greener, the closer. Nodes in all the different directions are explored uniformly, appearing more-or-less as a circular wavefront as Dijkstra's algorithm uses a heuristic identically equal to 0.

Let the node at which we are starting be called the **initial node**. Let the * Y* be the distance from the

**initial node**to

*Y*. Dijkstra's algorithm will assign some initial distance values and will try to improve them step by step.

Mark all nodes unvisited. Create a set of all the unvisited nodes called the

*unvisited set*.Assign to every node a tentative distance value: set it to zero for our initial node and to infinity for all other nodes. Set the initial node as current.

^{[13]}For the current node, consider all of its unvisited neighbours and calculate their

*tentative*distances through the current node. Compare the newly calculated*tentative*distance to the current assigned value and assign the smaller one. For example, if the current node*A*is marked with a distance of 6, and the edge connecting it with a neighbour*B*has length 2, then the distance to*B*through*A*will be 6 + 2 = 8. If B was previously marked with a distance greater than 8 then change it to 8. Otherwise, the current value will be kept.When we are done considering all of the unvisited neighbours of the current node, mark the current node as visited and remove it from the

*unvisited set*. A visited node will never be checked again.If the destination node has been marked visited (when planning a route between two specific nodes) or if the smallest tentative distance among the nodes in the

*unvisited set*is infinity (when planning a complete traversal; occurs when there is no connection between the initial node and remaining unvisited nodes), then stop. The algorithm has finished.Otherwise, select the unvisited node that is marked with the smallest tentative distance, set it as the new "current node", and go back to step 3.

When planning a route, it is actually not necessary to wait until the destination node is "visited" as above: the algorithm can stop once the destination node has the smallest tentative distance among all "unvisited" nodes (and thus could be selected as the next "current").

Description

Suppose you would like to find the *shortest path* between two intersections on a city map: a *starting point* and a *destination*. Dijkstra's algorithm initially marks the distance (from the starting point) to every other intersection on the map with *infinity*. This is done not to imply that there is an infinite distance, but to note that those intersections have not been visited yet. Some variants of this method leave the intersections' distances *unlabeled*. Now select the *current intersection* at each iteration. For the first iteration, the current intersection will be the starting point, and the distance to it (the intersection's label) will be *zero*. For subsequent iterations (after the first), the current intersection will be a *closest unvisited intersection* to the starting point (this will be easy to find).

From the current intersection, *update* the distance to every unvisited intersection that is directly connected to it. This is done by determining the *sum* of the distance between an unvisited intersection and the value of the current intersection and then relabeling the unvisited intersection with this value (the sum) if it is less than the unvisited intersection's current value. In effect, the intersection is relabeled if the path to it through the current intersection is shorter than the previously known paths. To facilitate shortest path identification, in pencil, mark the road with an arrow pointing to the relabeled intersection if you label/relabel it, and erase all others pointing to it. After you have updated the distances to each neighboring intersection, mark the current intersection as *visited* and select an unvisited intersection with minimal distance (from the starting point) – or the lowest label—as the current intersection. Intersections marked as visited are labeled with the shortest path from the starting point to it and will not be revisited or returned to.

Continue this process of updating the neighboring intersections with the shortest distances, marking the current intersection as visited, and moving onto a closest unvisited intersection until you have marked the destination as visited. Once you have marked the destination as visited (as is the case with any visited intersection), you have determined the shortest path to it from the starting point and can *trace your way back following the arrows in reverse*. In the algorithm's implementations, this is usually done (after the algorithm has reached the destination node) by following the nodes' parents from the destination node up to the starting node; that's why we also keep track of each node's parent.

This algorithm makes no attempt of direct "exploration" towards the destination as one might expect. Rather, the sole consideration in determining the next "current" intersection is its distance from the starting point. This algorithm therefore expands outward from the starting point, interactively considering every node that is closer in terms of shortest path distance until it reaches the destination. When understood in this way, it is clear how the algorithm necessarily finds the shortest path. However, it may also reveal one of the algorithm's weaknesses: its relative slowness in some topologies.

Pseudocode

A demo of Dijkstra's algorithm based on Euclidean distance. Red lines are the shortest path covering, i.e., connecting *u* and prev[*u*]. Blue lines indicate where relaxing happens, i.e., connecting *v* with a node *u* in *Q*, which gives a shorter path from the source to *v*.

In the following algorithm, the code u ← vertex in *Q* with min dist[u], searches for the vertex u in the vertex set Q that has the least dist[u] value. length(u, v) returns the length of the edge joining (i.e. the distance between) the two neighbor-nodes u and v. The variable alt on line 18 is the length of the path from the root node to the neighbor node v if it were to go through u. If this path is shorter than the current shortest path recorded for v, that current path is replaced with this alt path. The prev array is populated with a pointer to the "next-hop" node on the source graph to get the shortest route to the source.

If we are only interested in a shortest path between vertices source and target, we can terminate the search after line 15 if u = target. Now we can read the shortest path from source to target by reverse iteration:

Now sequence S is the list of vertices constituting one of the shortest paths from source to target, or the empty sequence if no path exists.

A more general problem would be to find all the shortest paths between source and target (there might be several different ones of the same length). Then instead of storing only a single node in each entry of prev[] we would store all nodes satisfying the relaxation condition. For example, if both r and source connect to target and both of them lie on different shortest paths through target (because the edge cost is the same in both cases), then we would add both r and source to prev[target]. When the algorithm completes, prev[] data structure will actually describe a graph that is a subset of the original graph with some edges removed. Its key property will be that if the algorithm was run with some starting node, then every path from that node to any other node in the new graph will be the shortest path between those nodes in the original graph, and all paths of that length from the original graph will be present in the new graph. Then to actually find all these shortest paths between two given nodes we would use a path finding algorithm on the new graph, such as depth-first search.

Using a priority queue

A min-priority queue is an abstract data type that provides 3 basic operations : add_with_priority(), decrease_priority() and extract_min(). As mentioned earlier, using such a data structure can lead to faster computing times than using a basic queue. Notably, Fibonacci heap (Fredman & Tarjan 1984) or Brodal queue offer optimal implementations for those 3 operations. As the algorithm is slightly different, we mention it here, in pseudo-code as well :

Instead of filling the priority queue with all nodes in the initialization phase, it is also possible to initialize it to contain only *source*; then, inside the **if** *alt* < dist[*v*] block, the node must be inserted if not already in the queue (instead of performing a decrease_priority operation).^{[5]} ^{[]}

Other data structures can be used to achieve even faster computing times in practice.^{[14]}

Proof of correctness

*Proof of Dijkstra's algorithm is constructed by induction on the number of visited nodes.*

*Invariant hypothesis*: For each visited node v, dist[v] is considered the shortest distance from source to v; and for each unvisited node u, dist[u] is assumed the shortest distance when traveling via visited nodes only, from source to u. This assumption is only considered if a path exists, otherwise the distance is set to infinity. (Note : we do not assume dist[u] is the actual shortest distance for unvisited nodes)

The base case is when there is just one visited node, namely the initial node source, in which case the hypothesis is trivial.

Otherwise, assume the hypothesis for *n-1* visited nodes. In which case, we choose an edge vu where u has the least dist[u] of any unvisited nodes and the edge vu is such that dist[u] = dist[v] + length[v,u]. dist[u] is considered to be the shortest distance from source to u because if there were a shorter path, and if w was the first unvisited node on that path then by the original hypothesis dist[w] > dist[u] which creates a contradiction. Similarly if there was a shorter path to u without using unvisited nodes, and if the last but one node on that path were w, then we would have had dist[u] = dist[w] + length[w,u], also a contradiction.

After processing u it will still be true that for each unvisited nodes w, dist[w] will be the shortest distance from source to w using visited nodes only, because if there were a shorter path that doesn't go by u we would have found it previously, and if there were a shorter path using u we would have updated it when processing u.

Running time

`Bounds of the running time of Dijkstra's algorithm on a graph with edgesEand verticesVcan be expressed as a function of the number of edges, denoted, and the number of vertices, denoted, usingbig-O notation. The complexity bound depends mainly on the data structure used to represent the setQ. In the following, upper bounds can be simplified becauseisfor any graph, but that simplification disregards the fact that in some problems, other upper bounds onmay hold.`

For any data structure for the vertex set Q, the running time is in

`whereandare the complexities of the`

*decrease-key*and*extract-minimum*operations inQ, respectively. The simplest version of Dijkstra's algorithm stores the vertex setQas an ordinary linked list or array, and extract-minimum is simply a linear search through all vertices inQ. In this case, the running time is.`If the graph is stored as an adjacency list, the running time for a dense graph (i.e., where) is`

- .

`Forsparse graphs, that is, graphs with far fewer thanedges, Dijkstra's algorithm can be implemented more efficiently by storing the graph in the form ofadjacency listsand using aself-balancing binary search tree,binary heap,pairing heap, orFibonacci heapas apriority queueto implement extracting minimum efficiently. To perform decrease-key steps in a binary heap efficiently, it is necessary to use an auxiliary data structure that maps each vertex to its position in the heap, and to keep this structure up to date as the priority queueQchanges. With a self-balancing binary search tree or binary heap, the algorithm requires`

`time in the worst case (wheredenotes the binary logarithm); for connected graphs this time bound can be simplified to. TheFibonacci heapimproves this to`

`When using binary heaps, theaverage casetime complexity is lower than the worst-case: assuming edge costs are drawn independently from a commonprobability distribution, the expected number of`

*decrease-key*operations is bounded by, giving a total running time of^{[5]}:199–200Practical optimizations and infinite graphs

In common presentations of Dijkstra's algorithm, initially all nodes are entered into the priority queue. This is, however, not necessary: the algorithm can start with a priority queue that contains only one item, and insert new items as they are discovered (instead of doing a decrease-key, check whether the key is in the queue; if it is, decrease its key, otherwise insert it).^{[5]} ^{[]} This variant has the same worst-case bounds as the common variant, but maintains a smaller priority queue in practice, speeding up the queue operations.^{[7]}

Moreover, not inserting all nodes in a graph makes it possible to extend the algorithm to find the shortest path from a single source to the closest of a set of target nodes on infinite graphs or those too large to represent in memory. The resulting algorithm is called *uniform-cost search* (UCS) in the artificial intelligence literature^{[7]}^{[15]}^{[16]} and can be expressed in pseudocode as

The complexity of this algorithm can be expressed in an alternative way for very large graphs: when *C** is the length of the shortest path from the start node to any node satisfying the "goal" predicate, each edge has cost at least ε, and the number of neighbors per node is bounded by b, then the algorithm's worst-case time and space complexity are both in *O*(*b*1+⌊*C** ⁄ *ε*⌋).^{[15]}

Further optimizations of Dijkstra's algorithm for the single-target case include bidirectional variants, goal-directed variants such as the A* algorithm (see § Related problems and algorithms), graph pruning to determine which nodes are likely to form the middle segment of shortest paths (reach-based routing), and hierarchical decompositions of the input graph that reduce *s*–*t* routing to connecting s and t to their respective "transit nodes" followed by shortest-path computation between these transit nodes using a "highway".^{[17]}
Combinations of such techniques may be needed for optimal practical performance on specific problems.^{[18]}

Specialized variants

`When arc weights are small integers (bounded by a parameter`

*C*), amonotone priority queuecan be used to speed up Dijkstra's algorithm. The first algorithm of this type was**Dial's algorithm**, which used abucket queueto obtain a running timethat depends on the weighteddiameterof a graph with integer edge weights (Dial 1969). The use of aVan Emde Boas treeas the priority queue brings the complexity to(Ahuja et al. 1990). Another interesting variant based on a combination of a newradix heapand the well-known Fibonacci heap runs in time(Ahuja et al. 1990). Finally, the best algorithms in this special case are as follows. The algorithm given by (Thorup 2000) runs intime and the algorithm given by (Raman 1997) runs intime.`Also, fordirected acyclic graphs, it is possible to find shortest paths from a given starting vertex in lineartime, by processing the vertices in atopological order, and calculating the path length for each vertex to be the minimum length obtained via any of its incoming edges.`

^{[19]}^{[20]}`In the special case of integer weights and undirected connected graphs, Dijkstra's algorithm can be completely countered with a linearcomplexity algorithm, given by (Thorup 1999).`

Related problems and algorithms

The functionality of Dijkstra's original algorithm can be extended with a variety of modifications. For example, sometimes it is desirable to present solutions which are less than mathematically optimal. To obtain a ranked list of less-than-optimal solutions, the optimal solution is first calculated. A single edge appearing in the optimal solution is removed from the graph, and the optimum solution to this new graph is calculated. Each edge of the original solution is suppressed in turn and a new shortest-path calculated. The secondary solutions are then ranked and presented after the first optimal solution.

Dijkstra's algorithm is usually the working principle behind link-state routing protocols, OSPF and IS-IS being the most common ones.

Unlike Dijkstra's algorithm, the Bellman–Ford algorithm can be used on graphs with negative edge weights, as long as the graph contains no negative cycle reachable from the source vertex *s*. The presence of such cycles means there is no shortest path, since the total weight becomes lower each time the cycle is traversed. (This statement assumes that a "path" is allowed to repeat vertices. In graph theory that is normally not allowed. In theoretical computer science it often is allowed.) It is possible to adapt Dijkstra's algorithm to handle negative weight edges by combining it with the Bellman-Ford algorithm (to remove negative edges and detect negative cycles), such an algorithm is called Johnson's algorithm.

The A* algorithm is a generalization of Dijkstra's algorithm that cuts down on the size of the subgraph that must be explored, if additional information is available that provides a lower bound on the "distance" to the target. This approach can be viewed from the perspective of linear programming: there is a natural linear program for computing shortest paths, and solutions to its dual linear program are feasible if and only if they form a consistent heuristic (speaking roughly, since the sign conventions differ from place to place in the literature). This feasible dual / consistent heuristic defines a non-negative reduced cost and A* is essentially running Dijkstra's algorithm with these reduced costs. If the dual satisfies the weaker condition of admissibility, then A* is instead more akin to the Bellman–Ford algorithm.

The process that underlies Dijkstra's algorithm is similar to the greedy process used in Prim's algorithm. Prim's purpose is to find a minimum spanning tree that connects all nodes in the graph; Dijkstra is concerned with only two nodes. Prim's does not evaluate the total weight of the path from the starting node, only the individual edges.

Breadth-first search can be viewed as a special-case of Dijkstra's algorithm on unweighted graphs, where the priority queue degenerates into a FIFO queue.

The fast marching method can be viewed as a continuous version of Dijkstra's algorithm which computes the geodesic distance on a triangle mesh.

Dynamic programming perspective

From a dynamic programming point of view, Dijkstra's algorithm is a successive approximation scheme that solves the dynamic programming functional equation for the shortest path problem by the **Reaching** method.^{[21]}^{[22]}^{[23]}

In fact, Dijkstra's explanation of the logic behind the algorithm,^{[24]} namely

Problem 2.Find the path of minimum total length between two given nodes and . We use the fact that, if is a node on the minimal path from to , knowledge of the latter implies the knowledge of the minimal path from to .

is a paraphrasing of Bellman's famous Principle of Optimality in the context of the shortest path problem.

See also

A* search algorithm

Bellman–Ford algorithm

Euclidean shortest path

Flood fill

Floyd–Warshall algorithm

Johnson's algorithm

Longest path problem

Parallel all-pairs shortest path algorithm
