A TDK SA90 Type II Compact Cassette
|Media type||Magnetic tape|
|Capacity||Typically 30 or 45 minutes of audio per side (C60 and C90 formats respectively), 120 minutes also available|
|Writemechanism||Magnetic recording head|
|Usage||Audio and data storage|
The Compact Cassette, Compact Audio Cassette or Musicassette (MC), also commonly called the cassette tape or simply tape or cassette, is an analog magnetic tape recording format for audio recording and playback. It was developed by Philips in Hasselt, Belgium, and introduced in September 1963. Compact Cassettes come in two forms, either already containing content as a prerecorded cassette (Musicassette), or as a fully recordable "blank" cassette. Both forms are reversible by the user.
The compact cassette technology was originally designed for dictation machines, but improvements in fidelity led the Compact Cassette to supplant the stereo 8-track cartridge and reel-to-reel tape recording in most non-professional applications. Its uses ranged from portable audio to home recording to data storage for early microcomputers. The first cassette player (although mono) designed for use in car dashboards was introduced in 1968. Between the early 1970s and the early 2000s, the cassette was one of the two most common formats for prerecorded music, first alongside the LP record and later the compact disc (CD).
Compact Cassettes contain two miniature spools, between which the magnetically coated, polyester-type plastic film (magnetic tape) is passed and wound. These spools and their attendant parts are held inside a protective plastic shell which is 4 by 2.5 by 0.5 inches (10 cm × 6.3 cm × 1.3 cm) at its largest dimensions. The tape itself was commonly referred to as "eighth-inch" tape, supposedly 1⁄8 inches wide, but it was slightly larger: 0.15 inches (3.81 mm). Two stereo pairs of tracks (four total) or two monaural audio tracks are available on the tape; one stereo pair or one monophonic track is played or recorded when the tape is moving in one direction and the second (pair) when moving in the other direction. This reversal is achieved either by flipping the cassette, or by the reversal of tape movement ("auto-reverse") when the mechanism detects that the tape has come to an end.
A TDK SA90 Type II Compact Cassette
|Media type||Magnetic tape|
|Capacity||Typically 30 or 45 minutes of audio per side (C60 and C90 formats respectively), 120 minutes also available|
|Writemechanism||Magnetic recording head|
|Usage||Audio and data storage|
Before the Compact Cassette
Wollensak portable reel-to-reel tape recorder
Cassettes of varying tape quality and playing time. The top is a Maxell MX (Type IV), bottom right is a TDK SA (Type II) and the bottom left is a TDK D (Type I)
Cassettes can be rewound with a pen or pencil
One of the first (portable) cassette recorders from Philips, the Typ EL 3302 (1968)
In 1935, decades before the introduction of the Compact Cassette, AEG released the first reel-to-reel tape recorder (in German: Tonbandgerät), with the commercial name "Magnetophon". It was based on the invention of the magnetic tape (1928) by Fritz Pfleumer, which used similar technology but with open reels (for which the tape was manufactured by BASF). These instruments were very expensive and relatively difficult to use and were therefore used mostly by professionals in radio stations and recording studios.
The reel alignment design had been made in 1948: the Protona Minifon, which was not the first attempt to fit magnetic audio tape into an easy to handle cartridge. In 1952 on the west side of the Atlantic Ocean, Bernard Cousino developed a completely different mechanical technology, where advanced designs followed over years due manufacturing licenses, cost and purposes.
In 1958, following four years of development, RCA Victor introduced the stereo, quarter-inch, reversible, reel-to-reel RCA tape cartridge. However, it was a large cassette (5 × 7 in, or 13 × 18 cm), and offered few pre-recorded tapes. Despite the multiple versions, it failed. Later the similar Elcaset also failed in the market.
Consumer use of magnetic tape machines took off in the early 1960s, after playback machines reached a comfortable, user-friendly design. This was aided by the introduction of transistors which replaced the bulky, fragile, and costly vacuum tubes of earlier designs. Reel-to-reel tape then became more suitable for household use, but still remained an esoteric product.
WIRAG, the Vienna division of Philips also developed a cartridge, described as single-hole cassette, adapted from its German described name Einloch-Kassette. Tape and tape speed were identical with the Compact Cassette. Grundig came up with the DC-International derived from blue prints of the Compact Cassette in 1965, but failed on the demand of distributing companies.
Introduction of the Compact Cassette
In 1962, Philips invented the Compact Cassette medium for audio storage, introducing it in Europe on 30 August 1963 at the Berlin Radio Show, and in the United States (under the Norelco brand) in November 1964, with the trademark name Compact Cassette. The team at Philips was led by Lou Ottens in Hasselt, Belgium.
"Philips was competing with Telefunken and Grundig in a race to establish its cassette tape as the worldwide standard, and it wanted support from Japanese electronics manufacturers." However, Philips' Compact Cassette became dominant as a result of Sony pressuring Philips to license the format to them free of charge. Philips also released the Norelco Carry-Corder 150 recorder/player in the US in November 1964. By 1966 over 250,000 recorders had been sold in the US alone and Japan soon became the major source of recorders. By 1968, 85 manufacturers had sold over 2.4 million players. By the end of the 1960s, the cassette business was worth an estimated 150 million dollars.
Popularity of music cassettes
The Sony Walkman
The mass production of "blank" (not yet recorded) Compact Cassettes began in 1964 in Hanover, Germany. Prerecorded music cassettes (also known as Music-Cassettes, and later just Musicassettes; M.C. for short) were launched in Europe in late 1965. The Mercury Record Company, a US affiliate of Philips, introduced M.C. to the US in July 1966. The initial offering consisted of 49 titles.
However, the system had been designed initially for dictation and portable use, with the audio quality of early players not well suited for music. Some early models also had an unreliable mechanical design. In 1971, the Advent Corporation introduced their Model 201 tape deck that combined Dolby type B noise reduction and chromium(IV) oxide (CrO2) tape, with a commercial-grade tape transport mechanism supplied by the Wollensak camera division of 3M Corporation. This resulted in the format being taken more seriously for musical use, and started the era of high fidelity cassettes and players.
Although the birth and growth of the cassette began in the 1960s, its cultural moment took place during the 1970s and 1980s. The cassette's popularity grew during these years as a result of being a more effective, convenient and portable way of listening to music. Stereo tape decks and boom boxes became some of the most highly sought-after consumer products of both decades. Portable pocket recorders and high-fidelity ("hi-fi") players, such as Sony's Walkman (1979), also enabled users to take their music with them anywhere with ease. The increasing user-friendliness of the cassette led to its popularity around the globe. The body of the Walkman was not much larger than the cassette tape itself, with mechanical keys on one side, or electronic buttons or a display on the face. Sony's WM-10 was even smaller than the cassette itself, and expanded to hold and play a cassette.
Like the transistor radio in the 1950s and 1960s, the portable CD player in the 1990s, and the MP3 player in the 2000s, the Walkman defined the portable music market for the decade of the '80s, with cassette sales overtaking those of LPs. Total vinyl record sales remained higher well into the 1980s due to greater sales of singles, although cassette singles achieved popularity for a period in the 1990s. Another barrier to cassettes overtaking vinyl in sales was shoplifting; compact cassettes were small enough that a thief could easily place one inside a pocket and walk out of a store without being noticed. To prevent this, retailers would place cassettes inside oversized "spaghetti box" containers or locked display cases, either of which would significantly inhibit browsing, thus reducing cassette sales. During the early 1980s some record labels sought to solve this problem by introducing new, larger packages for cassettes which would allow them to be displayed alongside vinyl records and compact discs, or giving them a further market advantage over vinyl by adding bonus tracks. Willem Andriessen wrote that the development in technology allowed "hardware designers to [...] discover and satisfy one of the collective desires of human beings all over the world, independent of region, climate, religion, culture, race, sex, age and education: the desire to enjoy music at any time, at any place, [...] in any desired sound quality and almost at any wanted price.
Apart from the purely technological advances cassettes brought, they also served as catalysts for social change. Their durability and ease of copying helped bring underground rock and punk music behind the Iron Curtain, creating a foothold for Western culture among the younger generations. For similar reasons, cassettes became popular in developing nations.
One of the most famous political uses of cassette tapes was the dissemination of sermons by the Ayatollah Khomeini throughout Iran before the 1979 Iranian Revolution, in which Khomeini urged the overthrow of the regime of the Shah, Mohammad Reza Pahlavi. In 1970s India, cassettes were blamed for bringing unwanted Christian and Islamic influences into traditionally Sikh and Hindu areas. Cassette technology was a booming market for pop music in India, drawing criticism from conservatives while at the same time creating a huge market for legitimate recording companies, as well as pirated tapes.
Between 1985 and 1992, the cassette tape was the most popular format in the UK and record labels experimented with innovative packaging designs. A designer during the era explained: "There was so much money in the industry at the time, we could try anything with design." The introduction of the cassette single, called a "cassingle", was also part of this era and featured a music single in Compact Cassette form. Until 2005, cassettes remained the dominant medium for purchasing and listening to music in some developing countries, but compact disc (CD) technology had superseded the Compact Cassette in the vast majority of music markets throughout the world by this time.
In Western Europe and North America, the market for cassettes declined sharply after its peak in the late 1980s. This was particularly noticeable with pre-recorded cassettes, the sales of which were overtaken by those of CDs during the early 1990s. By 1993, annual shipments of CD players had reached 5 million, up 21% from the year before; while cassette player shipments had dropped 7% to approximately 3.4 million. The decline continued, and in 2001 cassettes accounted for only 4% of all music sold. Since then, further decline occurred, with very few retailers stocking them because they are no longer issued by the major music labels.
Sales of pre-recorded music cassettes in the U.S. dropped from 442 million in 1990 to 274,000 by 2007. Another record low was registered in 2009, with 34,000 cassettes sold. Most of the major U.S. music companies had discontinued production of cassette tapes by 2003. However, as of 2012, blank cassettes were still being produced and are still sold at some retail stores, while facilities for cassette duplication remain available. Cassette recorders and players are gradually becoming more scarce, but are still available and featured in some hi-fi systems.
Cassettes remained popular for specific applications, such as car audio and telephone answering machines, well into the 1990s. Cassettes and their players were typically more rugged and resistant to dust, heat, and shocks than the main digital competitor, the CD. Their lower fidelity was not considered a serious drawback. However, the advent of "shock proof" buffering technology in CD players, the general heightening of consumer expectations, and the introduction of CD auto-changers meant that, by the early 2000s, the CD player rapidly replaced the cassette player as the default audio component in the majority of new vehicles in Europe and America. The last new car with an available cassette player was a 2010 Lexus SC 430.
While digital voice recorders are now common, microcassette recorders may be cheaper and of sufficient quality to serve as adjuncts or substitutes for note taking in business and educational settings. Audiobooks, church services, and other spoken word material are still frequently sold on cassette, as lower fidelity generally is not a drawback for such content, and some people prefer the convenience of the tape controls for rewinding to repeat a missed passage. While most publishers sell CD audiobooks, they usually also offered a cassette version at the same price well into the 2000s. In the audiobooks application, where recordings may span several hours, cassettes also have the advantage of holding up to 150 minutes of material, whereas the average CD holds less than 80.
21st century use
Although portable digital recorders are most common today, analog tape remains a desirable option for certain artists and consumers. Older genres like "dansband" may favor the format most familiar to their fans. Some musicians and DJs in the independent music community maintain a tradition of using and releasing cassettes due to its low cost and ease of use. Underground and DIY communities release regularly, and sometimes exclusively, on cassette format, particularly in experimental music circles and to a lesser extent in hardcore punk, death metal, and black metal circles, out of a fondness for the format. Even among major label stars, the form has at least one devotee: Thurston Moore claimed in 2009, "I only listen to cassettes."
In South Korea, the early English education boom for toddlers encourages a continuous demand for English language cassettes, as of 2011, due to the affordable cost.
In 2011, the Oxford English Dictionary removed the word "cassette player" from its 12th edition Concise version. Some media sources mistakenly claimed that the word "cassette tape" was being removed and this caused some media backlash. The term was removed to help make room for more than 400 new words being added to the dictionary.
In India, film and devotional music continued to be released in the cassette format due to its low cost until 2009.
National Audio Company in Missouri, the largest of the few remaining manufacturers of audiocassettes in the U.S., oversaw the mass production of the "Awesome Mix #1" cassette from the film Guardians of the Galaxy in 2014. They reported that they had produced more than 10 million tapes in 2014 and that sales were up 20 percent the following year, their best year since they opened in 1969. In 2016, cassette sales in the United States rose by 74% to 129,000. In 2018, following several years of shortage, National Audio Company began producing their own magnetic tape, becoming the world's only manufacturer of new tape stock.
Visualization of the magnetic field on a stereo cassette containing a 1kHz audio tone.
The cassette was a great step forward in convenience from reel-to-reel audio tape recording, although, because of the limitations of the cassette's size and speed, it initially compared poorly in quality. Unlike the 4-track stereo open-reel format, the two stereo tracks of each side lie adjacent to each other, rather than being interleaved with the tracks of the other side. This permitted monaural cassette players to play stereo recordings "summed" as mono tracks and permitted stereo players to play mono recordings through both speakers. The tape is 0.15 in (3.81 mm) wide, with each mono track 1.5 millimetres (0.059 in) wide, plus an unrecorded guard band between each track. In stereo, each track is further divided into a left and a right channel of 0.6 mm (0.024 in) each, with a gap of 0.3 mm (0.012 in). The tape moves past the playback head at 1 7⁄8 inches per second (4.76 cm/s), the speed being a continuation of the increasingly slower speed series in open-reel machines operating at 30, 15, 7 1⁄2, or 3 3⁄4 inches per second. For comparison, the typical open-reel 1⁄4-inch 4-track consumer format used tape that was 0.248 inches (6.3 mm) wide, each track .043 in (1.1 mm) wide, and running at either twice or four times the speed of a cassette.
Notches on the top surface of the Compact Cassette indicate its type. The rear-most cassette at the top of this picture, with only write-protect notches (here covered by write-protect tabs), is Type I, its tape consisting of iron oxide. The next cassette down, with additional notches adjacent to the write-protect tabs, is Type II, its tape consisting of chrome and cobalt. The bottom two cassettes, featuring the Type II notches plus an additional pair in the middle of the cassette, are Type IV (metal); note the removal of the tabs on the second of these, meaning the tape is write-protected.
Cassette tapes are made of a polyester-type plastic film with a magnetic coating. The original magnetic material was based on gamma ferric oxide (Fe2O3). Circa 1970, 3M Company developed a cobalt volume-doping process combined with a double-coating technique to enhance overall tape output levels. This product was marketed as "High Energy" under its Scotch brand of recording tapes. Inexpensive cassettes commonly are labeled "low-noise," but typically are not optimized for high frequency response. For this reason, some low-grade IEC Type I tapes have been marketed specifically as better suited for data storage than for sound recording.
At about the same time, chromium dioxide (CrO2) tape, later designated Type II, was introduced by DuPont, the inventor of the particle, and BASF, the inventor and longtime manufacturer of magnetic recording tape. Next, coatings using magnetite (Fe3O4) such as TDK's Audua were produced in an attempt to approach or exceed the sound quality of vinyl records. Cobalt-absorbed iron oxide (Avilyn) was introduced by TDK in 1974 and proved very successful. "Type IV" tapes using pure metal particles (as opposed to oxide formulations) were introduced in 1979 by 3M under the trade name Metafine. The tape coating on most cassettes sold today as either "normal" or "chrome" consists of ferric oxide and cobalt mixed in varying ratios (and using various processes); there are very few cassettes on the market that use a pure (CrO2) coating.
Simple voice recorders and earlier cassette decks are designed to work with standard ferric formulations. Newer tape decks usually are built with switches and later detectors for the different bias and equalization requirements for higher grade tapes. The most common, iron oxide tapes (defined by the IEC 60094 standard, as "Type I") use 120 µs equalization, while chrome and cobalt-absorbed tapes (IEC Type II) require 70 µs equalization. The recording bias levels also were different. BASF and Sony tried a dual layer tape with both ferric oxide and chrome dioxide known as 'ferrichrome' (FeCr) (IEC Type III), but these were available for only a short time in the 1970s. These also use 70 µs, just like Type II did. Metal cassettes (IEC Type IV) also use 70 µs equalization, and provide still further improvement in sound quality as well as durability. The quality normally is reflected in the price; Type I cassettes generally are the cheapest, and Type IV are usually the most expensive. BASF chrome tape used in commercially pre-recorded cassettes used type I equalization to allow greater high-frequency dynamic range for better sound quality, but the greater selling point for the music labels was that the Type I cassette shell could be used for both ferric and for chrome music cassettes.
Notches on top of the cassette shell indicate the type of tape. Type I cassettes have only write-protect notches, Type II have an additional pair next to the write protection ones, and Type IV (metal) have a third set near the middle of the top of the cassette shell. These allow later cassette decks to detect the tape type automatically and select the proper bias and equalization.
An exception to this standard were mechanical storytelling dolls from the 1980s (e.g. Teddy Ruxpin) which used the Type IV metal configuration cassette shell but had normal Type I voice grade tape inside. These toys used the Type IV notches to detect that a specially coded tape had been inserted, where the audio of the story is stored on the left channel and various cue tones to tell the doll's servos how and when to move along with the story on the right channel.
Most pre-recorded chrome cassettes require 120 µs equalisation and are treated as Type I (with notches as Type I ferric cassettes), to ensure compatibility with budget equipment.
Inside a cassette showing the leader at the beginning of side A. The tape "plays" from left to right (though, of course, an auto-reverse deck can play in either direction). The tape is pressed into close contact with the read-head by the pressure pad; guide rollers help keep the tape in the correct position. Smooth running is assisted by a slippery liner (slip sheet) between the spools and the shell; here the liner is transparent. The magnetic shield reduces pickup of stray signals by the heads of the player. The tab at the top-left corner of the shell permits recording on the current side.
Tape length usually is measured in minutes of total playing time. The most popular varieties (always marketed with a capital letter 'C' prefix) are C46 (23 minutes per side), C60 (30 minutes per side), C90, and C120. The C46 and C60 lengths typically are 15 to 16 micrometers (0.59 to 0.63 mils) thick, but C90s are 10 to 11 μm (0.39 to 0.43 mils) and (the less common) C120s are just 6 μm (0.24 mils) thick, rendering them more susceptible to stretching or breakage. Some vendors are more generous than others, providing 132 or 135 meters (433 or 443 feet) rather than 129 meters (423 feet) of tape for a C90 cassette. Even C180 tapes were available at one time, but these were extremely thin and fragile and suffered from such effects as print-through, which made them unsuitable for general use. 150 minute length is still available from Maxell (UR 150), Sony (CDixI 150) and TDK (TDK AE 150).
Although the TDK-D C180 was produced for a decade (1972–82), it is very rare, because of several technical flaws. The tape had to be so thin that it was nearly transparent and therefore had fewer particles to magnetize, resulting in a poor sound quality and even worse durability. It required a strong motor to be driven, and had high wow-and-flutter. Lastly, these tapes took a relatively long time to rewind.
Other lengths are (or were) also available from some vendors, including C10 and C15 (useful for saving data from early home computers and in telephone answering machines), C30, C40, C50, C54, C64, C70, C74, C80, C84, C100, C105, and C110. As late as 2010, Thomann still offered C10, C20, C30 and C40 IEC Type II tape cassettes for use with 4- and 8-track portastudios.
Some companies included a complimentary blank cassette with their portable cassette recorders in the early 1980s. Panasonic's was a C14 and came with a song recorded on side one, and a blank side two. Except for C74 and C100, such non-standard lengths always have been hard to find, and tend to be more expensive than the more popular lengths. Home taping enthusiasts may have found certain lengths useful for fitting an album neatly on one or both sides of a tape. For instance, the initial maximum playback time of Compact Discs was 74 minutes, explaining the relative popularity of C74 cassettes.
The "head gap" of a tape recorder refers to the space, in the direction of tape movement, between the ends of the pole pieces of the head. Without a gap the head would produce a "closed" magnetic field and so would not interact sufficiently with the magnetic domains on the tape.
The head gap width is 2 µm which gives a theoretical maximum frequency of about 12 kHz (at the standard speed of 1 7/8 ips or 4.76 cm/s). A narrower gap would give a higher frequency limit but also weaker magnetization. However, such limitations can be corrected through equalization in the recording and playback amplification sections, and narrower gaps were quite common, particularly in more expensive cassette machines. For example, the RP-2 series combined record/playback head (used in many Nakamichi cassette decks from the 1980s and 1990s) had a 1.2 µm gap, which allows for a playback frequency range of up to 20 kHz. A narrower gap width makes it harder to magnetize the tape, but is less important to the frequency range during recording than during playback, so a two-head solution can be applied: a dedicated recording head with a wide gap allowing effective magnetization of the tape and a dedicated playback head with a specific width narrow gap, possibly facilitating very high playback frequency ranges well above 20 kHz.
Separate record and playback heads were already a standard feature of more expensive reel-to-reel tape machines when cassettes were introduced, but their application to cassette recorders had to wait until demand developed for higher quality reproduction, and for sufficiently small heads to be produced.
All cassettes include a write protection mechanism to prevent re-recording and accidental erasure of important material. Each side of the cassette has a plastic tab on the top that may be broken off, leaving a small indentation in the shell. This indentation allows the entry of a sensing lever that prevents the operation of the recording function when the cassette is inserted into a cassette deck. If the cassette is held with one of the labels facing the user and the tape opening at the bottom, the write-protect tab for the corresponding side is at the top-left. Occasionally, manufacturers provided a movable panel that could be used to enable or disable write-protect on tapes.
If later required, a piece of adhesive tape can be placed over the indentation to bypass the protection, or (on some decks), the lever can be manually depressed to record on a protected tape. Extra care is required to avoid covering the additional indents on high bias or metal bias tape cassettes adjacent to the write-protect tabs.
In most cassettes, the magnetic tape is attached to each spool with a leader, usually made of strong plastic. This leader protects the weaker magnetic tape from the shock occurring when the tape reaches the end. Leaders can be complex: a plastic slide-in wedge anchors a short fully opaque plastic tape to the take-up hub; one or more tinted semi-opaque plastic segments follow; the clear leader (a tintless semi-opaque plastic segment) follows, which wraps almost all the way around the supply reel, before splicing to the magnetic tape itself. The clear leader spreads the shock load to a long stretch of tape instead of to the microscopic splice. Various patents have been issued detailing leader construction and associated tape player mechanisms to detect leaders. Cassette tape users would also use spare leaders to repair broken tapes.
The disadvantage with tape leaders was that the sound recording or playback did not start at the beginning of the tape, forcing the user to cue forward to the start of the magnetic section. For certain applications, such as dictation, special cassettes containing leaderless tapes were made, typically with stronger material and for use in machines that had more sophisticated end-of-tape prediction. Home computers that made use of cassettes as a more affordable alternative to floppy discs (e.g. Apple II, Commodore PET) were designed to not start writing or reading data until leaders had spooled past.
Endless loop cassette
Some cassettes were made to play a continuous loop of tape without stopping. Lengths available are from around 30 seconds to a standard full length. They are used in situations where a short message or musical jingle is to be played, either continuously or whenever a device is triggered, or whenever continuous recording or playing is needed. Some include a sensing foil on the tape to allow tape players to re-cue. From as early as 1969 various patents have been issued, covering such uses as uni-directional, bi-directional, and compatibility with auto-shut-off and anti-tape-eating mechanisms. One variant has a half-width loop of tape for an answering machine outgoing message, and another half-width tape on spools to record incoming messages.
Tape Guide via Security Mechanism (SM)
In order to wind up the tape more reliably, the former BASF (from 1998 EMTEC) patented the Special Mechanism or Security Mechanism advertised with the abbreviation SM in the early 1970s, which was temporarily taken over by Agfa under license. This feature each includes a rail to guide the tape to the spool and prevent an unclean roll from forming.
The competition responded by inserting additional deflector pins closer to the coils in the lower plastic case half. Some low-priced and pre-recorded compact cassettes were made without pulleys; the tape is pulled directly over the capstan drive. For the pressure of the tape to the head there is a thinner felt on a glued foam block instead of the usual felt on a leaf spring.
Cassette playback suffered from some flaws frustrating to both professionals and home recording enthusiasts. Tape speed could vary between devices, resulting in pitch that was too low or too high. Speed often was calibrated at the factory, and could not be changed by users. The slow tape speed increased tape hiss and noise, and in practice delivered higher values of wow and flutter. Different tape formulation and noise reduction schemes artificially boosted or cut high frequencies and inadvertently elevated noise levels. Noise reduction also adds some artifacts to the sound, which a trained ear can hear sometimes quite easily.
A common mechanical problem occurred when a worn-out or dirty player rotated the supply spool faster than the take-up spool or failed to release the heads from the tape upon ejection. This would cause the magnetic tape to be fed out through the bottom of the cassette and become tangled in the mechanism of the player. In these cases the player was said to have "eaten" or "chewed" the tape, often destroying the playability of the cassette. Splicing blocks, analogous to those used for open-reel 1/4" tape, were available and could be used to remove the damaged portion or repair the break in the tape.
Cassette players and recorders
A typical portable desktop cassette recorder from RadioShack
Nakamichi RX-505 cassette deck
An assortment of radio-cassette players, aka ghetto-blasters or "boomboxes"
A head cleaning cassette
The first cassette machines (e.g. the Philips EL 3300, introduced in August 1963) were simple mono-record and -playback units. Early machines required attaching an external dynamic microphone. Most units from the 1980s onwards also incorporated built-in condenser microphones, which have extended high-frequency response, but may also pick up noises from the recorder's motor.
A portable recorder format still common today is a long box, the width of a cassette, with a speaker at the top, a cassette bay in the middle, and "piano key" controls at the bottom edge. Another format is only slightly larger than the cassette, known popularly as the "Walkman" (a Sony trademark).
The markings of "piano key" controls soon were standardized, and are a legacy still emulated on many software control panels. These symbols are commonly a square for "stop", a vertically pointed triangle with a line under it for "eject", a right-pointing triangle for "play", double triangles for "fast-forward" and "rewind", a red dot for "record", and a vertically divided square (two rectangles side-by-side) for "pause".
Stereo recorders eventually evolved into high fidelity and were known as cassette decks, after the reel-to-reel decks. Hi-Fi cassette decks, in contrast to cassette recorders and cassette players, often didn't have built-in amplification or speakers. Many formats of cassette players and recorders have evolved over the years. Initially all were top loading, usually with cassette on one side, and VU meters and recording level controls on the other side. Older models used combinations of levers and sliding buttons for control.
A major innovation was the front-loading arrangement. Pioneer's angled cassette bay and the exposed bays of some Sansui models eventually were standardized as a front-loading door into which a cassette would be loaded. Later models would adopt electronic buttons, and replace conventional meters (which could be "pegged" when overloaded) with electronic LED or vacuum fluorescent displays, with level controls typically being controlled by either rotary controls or side-by-side sliders. BIC and Marantz briefly offered models that could be run at double speeds, but Nakamichi was widely recognized as one of the first companies to create decks that rivaled reel-to-reel decks with frequency response from the full 20–20,000 Hz range, low noise, and very low wow and flutter. The 3-head closed-loop dual capstan Nakamichi 1000 (1973) is one early example. Unlike typical cassette decks that use a single head for both record and playback plus a second head for erasing, the Nakamichi 1000, like the better reel-to-reel recorders, used three separate heads to optimize these functions.
Other contenders for the highest "HiFi" quality on this medium were two companies already widely known for their excellent quality reel-to-reel tape recorders: Tandberg and Revox (consumer brand of the Swiss professional Studer company for studio equipment). Tandberg started with combi-head machines, such as the TCD 300, and continued with the TCD 3x0 series with separate playback and recording heads. All TCD-models possessed dual-capstan drives, belt-driven from a single capstan motor and two separate reel motors. Frequency range extended to 18 kHz. After a disastrous overinvestment in colour television production, Tandberg folded and revived without the HiFi-branch these came from.
Revox went one step further: after much hesitation about whether to accept cassettes as a medium capable for meeting their strict standards from reel-to-reel recorders at all, they produced their B710MK I (Dolby B) and MK II (Dolby B&C) machines. Both cassette units possessed double capstan drives, but with two independent, electronically controlled capstan motors and two separate reel motors. The head assembly moved by actuating a damped solenoid movement, eliminating all belt drives and other wearable parts. These machines rivaled the Nakamichi in frequency and dynamic range. The B710MKII also achieved 20–20,000 Hz and dynamics of over 72 dB with Dolby C on chrome and slightly less dynamic range, but greater headroom with metal tapes and Dolby C. Revox adjusted the frequency range on delivery with many years of use in mind: when new, the frequency curve went upwards a few dB at 15–20 kHz, aiming for flat response after 15 years of use, and headwear to match.
A last step taken by Revox produced even more-advanced cassette drives with electronic finetuning of bias and equalization during recording. Revox also produced amplifiers, a very expensive FM tuner, and a pickup with a special parallel-arm mechanism of their own design. After releasing that product, Studer encountered financial difficulties. It had to save itself by folding its Revox-branch and all its consumer products (except their last reel-to-reel recorder, the B77).
While some might say that Nakamichi violated the tape recording standards to achieve the highest dynamics possible, producing non-compatible cassettes for playback on other machines, the reasons for this are more complex than they appear on the surface. Different interpretations of the cassette standard resulted in a 4 dB ambiguity at 16 kHz. Technically, both camps in this debate were still within the original cassette specification as no tolerance for frequency response was provided above 12.5 kHz and all calibration tones above 12.5 kHz are considered optional. But also Nakamichi is not error-prone. Decreasing noise at 16 kHz also decreases the maximum signal level at 16 kHz, the HighFrequency-Dynamics stay almost constant.
A third company, the Danish Bang & Olufsen improved the Dolby HX "head room extension" system for reliably reducing tape saturation effects at short wavelength (high frequencies) despite higher bias levels. This advanced method was called Dolby HX Pro in full and patented. HX Pro was adopted by many other high-end manufacturers.
As they became aimed at more casual users, fewer decks had microphone inputs. Dual decks became popular and incorporated into home entertainment systems of all sizes for tape dubbing. Although the quality would suffer each time a source was copied, there are no mechanical restrictions on copying from a record, radio, or another cassette source. Even as CD recorders are becoming more popular, some incorporate cassette decks for professional applications.
Another format that made an impact on culture in the 1980s was the radio-cassette, aka the "boom box" (a name used commonly only in English-speaking North America), which combined the portable cassette deck with a radio tuner and speakers capable of producing significant sound levels. These devices became synonymous with urban youth culture in entertainment, which led to the somewhat derisive nickname "ghetto blaster." The boom box allowed people to enjoy music on the go and share it with friends. This also led to such cultural practises as breakdancing.
Applications for car stereos varied widely. Auto manufacturers in the U.S. typically would fit a cassette slot into their standard large radio faceplates. Europe and Asia would standardize on DIN and double DIN sized faceplates. In the 1980s, a high-end installation would have a Dolby AM/FM cassette deck, and they rendered the 8-track cartridge obsolete in car installations because of space, performance, and audio quality. In the 1990s and 2000s, as the cost of building CD players declined, many manufacturers offered a CD player. The CD player eventually supplanted the cassette deck as standard equipment, but some cars, especially those targeted at older drivers, were offered with the option of a cassette player, either by itself or sometimes in combination with a CD slot. Most new cars can still accommodate aftermarket cassette players, and the auxiliary jack advertised for MP3 players can be used also with portable cassette players, but 2011 was the first model year for which no manufacturer offered factory-installed cassette players.
Although the cassettes themselves were relatively durable, the players required regular maintenance to perform properly. Head cleaning may be done with long swabs, soaked with isopropyl alcohol, or cassette-shaped devices that could be inserted into a tape deck to remove buildup of iron-oxide from the heads, tape-drive capstan, and pinch-roller. Some otherwise normal recording tapes included sections of leader that could clean the tape heads. One of the concerns of the time however was the use of abrasive cleaning tape. Some of the cleaning tapes actually felt rough to the touch and were considered damaging to the heads. Similarly shaped demagnetizers used magnets to degauss the deck, which kept sound from becoming distorted (see Cassette demagnetizer).
A dual cassette-based Panasonic answering machine
The Compact Cassette originally was intended for use in dictation machines. In this capacity, some later-model cassette-based dictation machines could also run the tape at half speed (15⁄16 in/s) as playback quality was not critical. The cassette soon became a popular medium for distributing prerecorded music—initially through The Philips Record Company (and subsidiary labels Mercury and Philips in the U.S.). As of 2009, one still finds cassettes used for a variety of purposes, such as journalism, oral history, meeting and interview transcripts, audio-books, and so on. Police are still big buyers of cassette tapes, as some lawyers "don't trust digital technology for interviews". However, they are starting to give way to Compact Discs and more "compact" digital storage media. Prerecorded cassettes were also employed as a way of providing chemotherapy information to recently diagnosed cancer patients as studies found anxiety and fear often gets in the way of the information processing.
The cassette quickly found use in the commercial music industry. One artifact found on some commercially produced music cassettes was a sequence of test tones, called SDR (Super Dynamic Range, also called XDR, or eXtended Dynamic Range) soundburst tones, at the beginning and end of the tape, heard in order of low frequency to high. These were used during SDR/XDR's duplication process to gauge the quality of the tape medium. Many consumers objected to these tones since they were not part of the recorded music.
News reporting, documentary, and human interest broadcast operations often used portable Marantz PMD-series recorders for the recording of speech interviews. The key advantages of the Marantz portable recorders were the accommodation of professional microphones with an XLR connector, normal and double tape speed recording for extended frequency response, Dolby and dbx noise reduction systems, manual or automatic gain control (AGC) level control, peak limiter, multiple tape formulation accommodation, microphone and line level input connections, unbalanced RCA stereo input and output connections, live or tape monitoring, VU meter, headphone jack, playback pitch control, and operation on AC power or batteries optimized for long duration. Unlike less-expensive portable recorders that were limited to automatic gain control (AGC) recording schemes, the manual recording mode preserved low noise dynamics and avoided the automatic elevation of noise.
Beginning in 1979, Tascam introduced the Portastudio line of four- and eight-track cassette recorders for home-studio use.
In the simplest configuration, rather than playing a pair of stereo channels of each side of the cassette, the typical "portastudio" used a four-track tape head assembly to access four tracks on the cassette at once (with the tape playing in one direction). Each track could be recorded to, erased, or played back individually, allowing musicians to overdub themselves and create simple multitrack recordings easily, which could then be mixed down to a finished stereo version on an external machine. To increase audio quality in these recorders, the tape speed sometimes was doubled to 33/4 inches per second, in comparison to the standard 17⁄8 ips; additionally, dbx, Dolby B or Dolby C noise reduction provided compansion (compression of the signal during recording with equal and opposite expansion of the signal during playback), which yields increased dynamic range by lowering the noise level and increasing the maximum signal level before distortion occurs. Multi-track cassette recorders with built-in mixer and signal routing features ranged from easy-to-use beginner units up to professional-level recording systems.
Although professional musicians typically used multitrack cassette machines only as "sketchpads", Bruce Springsteen's "Nebraska" was recorded entirely on a four-track cassette tape.
A Magnavox dual deck recorder with high-speed dubbing. Doors are open showing capstans.
Most cassettes were sold blank, and used for recording (dubbing) the owner's records (as backup, to play in the car, or to make mixtape compilations), their friends' records, or music from the radio. This practice was condemned by the music industry with such alarmist slogans as "Home Taping Is Killing Music". However, many claimed that the medium was ideal for spreading new music and would increase sales, and strongly defended their right to copy at least their own records onto tape. For a limited time in the early 1980s Island Records sold chromium dioxide "One Plus One" cassettes that had an album prerecorded on one side and the other was left blank for the purchaser to use, another early example being the 1980 "C·30 C·60 C·90 Go" cassingle by Bow Wow Wow where the b-side of the tape was blank, allowing the purchaser to record their own b-side. Cassettes were also a boon to people wishing to tape concerts (unauthorized or authorized) for sale or trade, a practice tacitly or overtly encouraged by many bands, such as the Grateful Dead, with a more counterculture bent. Blank cassettes also were an invaluable tool to spread the music of unsigned acts, especially within tape trading networks.
Various legal cases arose surrounding the dubbing of cassettes. In the UK, in the case of CBS Songs v. Amstrad (1988), the House of Lords found in favor of Amstrad that producing equipment that facilitated the dubbing of cassettes, in this case a high-speed twin cassette deck that allowed one cassette to be copied directly onto another, did not constitute copyright infringement by the manufacturer. In a similar case, a shop owner who rented cassettes and sold blank tapes was not liable for copyright infringement even though it was clear that his customers likely were dubbing them at home. In both cases, the courts held that manufacturers and retailers could not be held accountable for the actions of consumers.
As an alternative to home dubbing, in the late 1980s, the Personics company installed booths in record stores across America that allowed customers to make personalized mixtapes from a digitally encoded back-catalogue with customised printed covers.
Educational, religious, corporate, military, and broadcasting institutions benefited from messaging proliferation through accessibly priced duplicators, offered by Telex Communications, Wollensak, Sony, and others. The duplicators would operate at double (or greater) tape speed. Systems were scalable, enabling the user to purchase initially one "master" unit (typically with 3 "copy" bays) and add "slave" units for expanded duplication abilities.
A C2N Datassette recorder for Commodore computers
German-made cassettes sold for computer data recording, mid 1980s
A streamer cassette for data storage, adapted from the audio Compact Cassette format
The Hewlett Packard HP 9830 was one of the first desktop computers in the early 1970s to use automatically controlled cassette tapes for storage. It could save and find files by number, using a clear leader to detect the end of tape. These would be replaced by specialized cartridges, such as the 3M DC-series. Many of the earliest microcomputers implemented the Kansas City standard for digital data storage. Most home computers of the late 1970s and early 1980s could use cassettes for data storage as a cheaper alternative to floppy disks, though users often had to manually stop and start a cassette recorder. Even the first version of the IBM PC of 1981 had a cassette port and a command in its ROM BASIC programming language to use it. However, IBM cassette tape was seldom used, as by 1981 floppy drives had become commonplace in high-end machines.
Nintendo's Famicom had an available cassette data recorder, used for saving programs created with the hardware's version of BASIC and saving progress in some Famicom games. It was never released outside Japan, but the North American versions of some of the compatible games can technically be used with it, since many early copies of two of the games (Excitebike and Wrecking Crew) are actually just the Japanese versions in a different shell, and Nintendo intentionally included compatibility in later prints of those titles and in other games since they were planning on releasing the recorder in the region anyway.
The typical encoding method for computer data was simple FSK, which resulted in data rates of typically 500 to 2000 bit/s, although some games used special, faster-loading routines, up to around 4000 bit/s. A rate of 2000 bit/s equates to a capacity of around 660 kilobytes per side of a 90-minute tape.
Among home computers that used primarily data cassettes for storage in the late 1970s were Commodore PET (early models of which had a cassette drive built-in), TRS-80 and Apple II, until the introduction of floppy disk drives and hard drives in the early 1980s made cassettes virtually obsolete for day-to-day use in the US. However, they remained in use on some portable systems such as the TRS-80 Model 100 line—often in microcassette form—until the early 1990s.
Floppy disk storage had become the standard data storage medium in the United States by the mid-1980s; for example, by 1983 the majority of software sold by Atari Program Exchange was on floppy. Cassette remained more popular for 8-bit computers such as the Commodore 64, ZX Spectrum, MSX, and Amstrad CPC 464 in many countries such as the United Kingdom (where 8-bit software was mostly sold on cassette until that market disappeared altogether in the early 1990s). Reliability of cassettes for data storage is inconsistent, with many users recalling repeated attempts to load video games; the Commodore Datasette used very reliable, but slow, digital encoding. In some countries, including the United Kingdom, Poland, Hungary, and the Netherlands, cassette data storage was so popular that some radio stations would broadcast computer programs that listeners could record onto cassette and then load into their computer. See BASICODE.
The use of better modulation techniques, such as QPSK or those used in modern modems, combined with the improved bandwidth and signal to noise ratio of newer cassette tapes, allowed much greater capacities (up to 60 MB) and data transfer speeds of 10 to 17 kbit/s on each cassette. They found use during the 1980s in data loggers for scientific and industrial equipment.
The cassette was adapted into what is called a streamer cassette (also known as a "D/CAS" cassette), a version dedicated solely for data storage, and used chiefly for hard disk backups and other types of data. Streamer cassettes look almost exactly the same as a standard cassette, with the exception of having a notch about one quarter-inch wide and deep situated slightly off-center at the top edge of the cassette. Streamer cassettes also have a re-usable write-protect tab on only one side of the top edge of the cassette, with the other side of the top edge having either only an open rectangular hole, or no hole at all. This is due to the entire one-eighth inch width of the tape loaded inside being used by a streamer cassette drive for the writing and reading of data, hence only one side of the cassette being used. Streamer cassettes can hold anywhere from 250 kilobytes to 600 megabytes of data.
Size comparison of Elcaset (left) with standard Compact Cassette
A Compact Cassette and a Microcassette
Elcaset was a short-lived audio format created by Sony in 1976 that was about twice the size, using larger tape and a higher recording speed. Unlike the original cassette, the Elcaset was designed from the outset for sound quality. It was never widely accepted, as the quality of standard cassette decks rapidly approached high fidelity.
Technical development of the cassette effectively ceased when digital recordable media, such as DAT and MiniDisc, were introduced in the late 1980s and early 1990s. Anticipating the switch from analog to digital format, major companies, such as Sony, shifted their focus to new media. In 1992, Philips introduced the Digital Compact Cassette (DCC), a DAT-like tape in almost the same shell as a Compact Cassette. It was aimed primarily at the consumer market. A DCC deck could play back both types of cassettes. Unlike DAT, which was accepted in professional usage because it could record without lossy compression effects, DCC failed in both home and mobile environments, and was discontinued in 1996.
The microcassette largely supplanted the full-sized cassette in situations where voice-level fidelity is all that is required, such as in dictation machines and answering machines. Microcassettes have in turn given way to digital recorders of various descriptions. Since the rise of cheap CD-R discs, and flash memory-based digital audio players, the phenomenon of "home taping" has effectively switched to recording to a Compact Disc or downloading from commercial or music sharing Web sites.
Because of consumer demand, the cassette has remained influential on design, more than a decade after its decline as a media mainstay. As the Compact Disc grew in popularity, cassette-shaped audio adapters were developed to provide an economical and clear way to obtain CD functionality in vehicles equipped with cassette decks but no CD player. A portable CD player would have its analog line-out connected to the adapter, which in turn fed the signal to the head of the cassette deck. These adapters continue to function with MP3 players and smartphones, and generally are more reliable than the FM transmitters that must be used to adapt CD players and digital audio players to car stereo systems. Digital audio players shaped as cassettes have also become available, which can be inserted into any cassette player and communicate with the head as if they were normal cassettes.
