7.35×51mm Carcano
7.35×51mm Carcano
7.35×51mm Carcano | |
---|---|
Type | Rifle |
Place of origin | Kingdom of Italy |
Service history | |
Used by | Italy, Finland, Nazi Germany |
Wars | World War II, others |
Specifications | |
Parent case | 6.5 mm Carcano |
Case type | Rimless bottleneck |
Bullet diameter | 7.57 mm (0.298 in) |
Neck diameter | 8.32 mm (0.328 in) |
Shoulder diameter | 10.85 mm (0.427 in) |
Base diameter | 11.40 mm (0.449 in) |
Rim diameter | 11.40 mm (0.449 in) |
Case length | 51.50 mm (2.028 in) |
Overall length | 73.70 mm (2.902 in) |
Case capacity | 3.26 cm3(50.3 gr H2O) |
Maximum pressure | 350 MPa (51,000 psi) |
The 7.35×51mm Carcano is an Italian rifle cartridge and a now obsolete caliber designed to replace the 6.5×52mm Carcano in the Carcano rifles of the Italian military. The 7.35 used Spitzer-style projectile to minimize the air resistance in flight.
7.35×51mm Carcano | |
---|---|
Type | Rifle |
Place of origin | Kingdom of Italy |
Service history | |
Used by | Italy, Finland, Nazi Germany |
Wars | World War II, others |
Specifications | |
Parent case | 6.5 mm Carcano |
Case type | Rimless bottleneck |
Bullet diameter | 7.57 mm (0.298 in) |
Neck diameter | 8.32 mm (0.328 in) |
Shoulder diameter | 10.85 mm (0.427 in) |
Base diameter | 11.40 mm (0.449 in) |
Rim diameter | 11.40 mm (0.449 in) |
Case length | 51.50 mm (2.028 in) |
Overall length | 73.70 mm (2.902 in) |
Case capacity | 3.26 cm3(50.3 gr H2O) |
Maximum pressure | 350 MPa (51,000 psi) |
Description
After reports of inadequate performance of the 6.5×52mm Mannlicher–Carcano at both short and long ranges[1][2] during the campaigns in Italian North Africa (1924-1934), and the Second Italo-Abyssinian War (1935/36), the Italian army introduced a new short rifle in 1938, the Modello 1938, together with a new cartridge in 7.35x51mm caliber. In addition to the slightly larger caliber, Italian ordnance designers introduced a spitzer-type bullet for the new cartridge, with the tip filled with aluminum to produce an unstable (tumbling) projectile upon impact with soft tissue (a design most likely copied from the .303 British Mk VII bullet). Although the intention was to create a more powerful and precise rifle cartridge, the decision to adopt a lighter bullet than in the 6.5 mm Carcano,[3] and various design problems of the 91/38 rifle, did not permit the cartridge to achieve the intended success.
