Spectral line

Spectral line

Emission lines (discrete spectrum)

Emission lines (discrete spectrum)

Continuous spectrum

Continuous spectrum

Absorption lines for air, under indirect illumination, with the direct light source not visible, so that the gas is not directly between source and detector.

Absorption lines for air, under indirect illumination, with the direct light source not visible, so that the gas is not directly between source and detector.

A spectral line is a dark or bright line in an otherwise uniform and continuous spectrum, resulting from emission or absorption of light in a narrow frequency range, compared with the nearby frequencies. Spectral lines are often used to identify atoms and molecules. These "fingerprints" can be compared to the previously collected "fingerprints" of atoms and molecules,[2] and are thus used to identify the atomic and molecular components of stars and planets, which would otherwise be impossible.

Types of line spectra

Continuous spectrum of an incandescent lamp (mid) and discrete spectrum lines of a fluorescent lamp (bottom)

Continuous spectrum of an incandescent lamp (mid) and discrete spectrum lines of a fluorescent lamp (bottom)

Spectral lines are the result of interaction between a quantum system (usually atoms, but sometimes molecules or atomic nuclei) and a single photon. When a photon has about the right amount of energy to allow a change in the energy state of the system (in the case of an atom this is usually an electron changing orbitals), the photon is absorbed. Then it will be spontaneously re-emitted, either in the same frequency as the original or in a cascade, where the sum of the energies of the photons emitted will be equal to the energy of the one absorbed (assuming the system returns to its original state).

A spectral line may be observed either as an emission line or an absorption line. Which type of line is observed depends on the type of material and its temperature relative to another emission source. An absorption line is produced when photons from a hot, broad spectrum source pass through a cold material. The intensity of light, over a narrow frequency range, is reduced due to absorption by the material and re-emission in random directions. By contrast, a bright emission line is produced when photons from a hot material are detected in the presence of a broad spectrum from a cold source. The intensity of light, over a narrow frequency range, is increased due to emission by the material.

Spectral lines are highly atom-specific, and can be used to identify the chemical composition of any medium capable of letting light pass through it.

Several elements were discovered by spectroscopic means, including helium, thallium, and caesium. Spectral lines also depend on the physical conditions of the gas, so they are widely used to determine the chemical composition of stars and other celestial bodies that cannot be analyzed by other means, as well as their physical conditions.

Mechanisms other than atom-photon interaction can produce spectral lines.

Depending on the exact physical interaction (with molecules, single particles, etc.), the frequency of the involved photons will vary widely, and lines can be observed across the electromagnetic spectrum, from radio waves to gamma rays.

Nomenclature

Strong spectral lines in the visible part of the spectrum often have a unique Fraunhofer line designation, such as K for a line at 393.366 nm emerging from singly ionized Ca+, though some of the Fraunhofer "lines" are blends of multiple lines from several different species. In other cases the lines are designated according to the level of ionization by adding a Roman numeral to the designation of the chemical element, so that Ca+ also has the designation Ca II. Neutral atoms are denoted with the roman number I, singly ionized atoms with II, and so on, so that for example Fe IX (IX, roman 9) represents eight times ionized iron. More detailed designations usually include the line wavelength and may include a multiplet number (for atomic lines) or band designation (for molecular lines). Many spectral lines of atomic hydrogen also have designations within their respective series, such as the Lyman series or Balmer series. Originally all spectral lines were classified into series of Principle series, Sharp series, and Diffuse series. These series exist across atoms of all elements and the Rydberg-Ritz combination principle is a formula that predicts the pattern of lines to be found in all atoms of the elements. For this reason, the NIST spectral line database contains a column for Ritz calculated lines. These series were later associated with suborbitals.

Line broadening and shift

A spectral line extends over a range of frequencies, not a single frequency (i.e., it has a nonzero linewidth).

In addition, its center may be shifted from its nominal central wavelength.

There are several reasons for this broadening and shift.

These reasons may be divided into two general categories – broadening due to local conditions and broadening due to extended conditions.

Broadening due to local conditions is due to effects which hold in a small region around the emitting element, usually small enough to assure local thermodynamic equilibrium. Broadening due to extended conditions may result from changes to the spectral distribution of the radiation as it traverses its path to the observer. It also may result from the combining of radiation from a number of regions which are far from each other.

Broadening due to local effects

Natural broadening

The uncertainty principle relates the lifetime of an excited state (due to spontaneous radiative decay or the Auger process) with the uncertainty of its energy. A short lifetime will have a large energy uncertainty and a broad emission. This broadening effect results in an unshifted Lorentzian profile. The natural broadening can be experimentally altered only to the extent that decay rates can be artificially suppressed or enhanced.[3]

Thermal Doppler broadening

The atoms in a gas which are emitting radiation will have a distribution of velocities.

Each photon emitted will be "red"- or "blue"-shifted by the Doppler effect depending on the velocity of the atom relative to the observer. The higher the temperature of the gas, the wider the distribution of velocities in the gas. Since the spectral line is a combination of all of the emitted radiation, the higher the temperature of the gas, the broader the spectral line emitted from that gas. This broadening effect is described by a Gaussian profile and there is no associated shift.

Pressure broadening

The presence of nearby particles will affect the radiation emitted by an individual particle.

There are two limiting cases by which this occurs:

  • Impact pressure broadening or collisional broadening: The collision of other particles with the emitting particle interrupts the emission process, and by shortening the characteristic time for the process, increases the uncertainty in the energy emitted (as occurs in natural broadening).[4] The duration of the collision is much shorter than the lifetime of the emission process. This effect depends on both the density and the temperature of the gas. The broadening effect is described by a Lorentzian profile and there may be an associated shift.

  • Quasistatic pressure broadening: The presence of other particles shifts the energy levels in the emitting particle, thereby altering the frequency of the emitted radiation. The duration of the influence is much longer than the lifetime of the emission process. This effect depends on the density of the gas, but is rather insensitive to temperature. The form of the line profile is determined by the functional form of the perturbing force with respect to distance from the perturbing particle. There may also be a shift in the line center. The general expression for the lineshape resulting from quasistatic pressure broadening is a 4-parameter generalization of the Gaussian distribution known as a stable distribution.[[5]](https://portal.issn.org/resource/ISSN/the original)

Pressure broadening may also be classified by the nature of the perturbing force as follows:

  • Linear Stark broadening occurs via the linear Stark effect, which results from the interaction of an emitter with an electric field of a charged particle at a distance, causing a shift in energy that is linear in the field strength.

  • Resonance broadening occurs when the perturbing particle is of the same type as the emitting particle, which introduces the possibility of an energy exchange process.

  • Quadratic Stark broadening occurs via the quadratic Stark effect, which results from the interaction of an emitter with an electric field, causing a shift in energy that is quadratic in the field strength.

  • Van der Waals broadening occurs when the emitting particle is being perturbed by van der Waals forces. For the quasistatic case, a van der Waals profile[1] is often useful in describing the profile. The energy shift as a function of distance is given in the wings by e.g. the Lennard-Jones potential.

Inhomogeneous broadening

Inhomogeneous broadening is a general term for broadening because some emitting particles are in a different local environment from others, and therefore emit at a different frequency. This term is used especially for solids, where surfaces, grain boundaries, and stoichiometry variations can create a variety of local environments for a given atom to occupy. In liquids, the effects of inhomogeneous broadening is sometimes reduced by a process called motional narrowing

Broadening due to non-local effects

Certain types of broadening are the result of conditions over a large region of space rather than simply upon conditions that are local to the emitting particle.

Opacity broadening

Electromagnetic radiation emitted at a particular point in space can be reabsorbed as it travels through space.

This absorption depends on wavelength.

The line is broadened because the photons at the line center have a greater reabsorption probability than the photons at the line wings.

Indeed, the reabsorption near the line center may be so great as to cause a self reversal in which the intensity at the center of the line is less than in the wings. This process is also sometimes called self-absorption.

Macroscopic Doppler broadening

Radiation emitted by a moving source is subject to Doppler shift due to a finite line-of-sight velocity projection. If different parts of the emitting body have different velocities (along the line of sight), the resulting line will be broadened, with the line width proportional to the width of the velocity distribution. For example, radiation emitted from a distant rotating body, such as a star, will be broadened due to the line-of-sight variations in velocity on opposite sides of the star. The greater the rate of rotation, the broader the line. Another example is an imploding plasma shell in a Z-pinch.

Radiative broadening

Radiative broadening of the spectral absorption profile occurs because the on-resonance absorption in the center of the profile is saturated at much lower intensities than the off-resonant wings.

Therefore, as intensity rises, absorption in the wings rises faster than absorption in the center, leading to a broadening of the profile.

Radiative broadening occurs even at very low light intensities.

Combined effects

Each of these mechanisms can act in isolation or in combination with others.

Assuming each effect is independent, the observed line profile is a convolution of the line profiles of each mechanism.

For example, a combination of the thermal Doppler broadening and the impact pressure broadening yields a Voigt profile.

However, the different line broadening mechanisms are not always independent.

For example, the collisional effects and the motional Doppler shifts can act in a coherent manner, resulting under some conditions even in a collisional narrowing, known as the Dicke effect.

Spectral lines of chemical elements

Visible light

For each element, the following table shows the spectral lines which appear in the visible spectrum, from about 400nm-700nm.

Spectral lines of thechemical elements
ElementZSymbolSpectral lines
hydrogen1H
helium2He
lithium3Li
beryllium4Be
boron5B
carbon6C
nitrogen7N
oxygen8O
fluorine9F
neon10Ne
sodium11Na
magnesium12Mg
aluminium13Al
silicon14Si
phosphorus15P
sulfur16S
chlorine17Cl
argon18Ar
potassium19K
calcium20Ca
scandium21Sc
titanium22Ti
vanadium23V
chromium24Cr
manganese25Mn
iron26Fe
cobalt27Co
nickel28Ni
copper29Cu
zinc30Zn
gallium31Ga
germanium32Ge
arsenic33As
selenium34Se
bromine35Br
krypton36Kr
rubidium37Rb
strontium38Sr
yttrium39Y
zirconium40Zr
niobium41Nb
molybdenum42Mo
technetium43Tc
ruthenium44Ru
rhodium45Rh
palladium46Pd
silver47Ag
cadmium48Cd
indium49In
tin50Sn
antimony51Sb
tellurium52Te
iodine53I
xenon54Xe
caesium55Cs
barium56Ba
lanthanum57La
cerium58Ce
praseodymium59Pr
neodymium60Nd
promethium61Pm
samarium62Sm
europium63Eu
gadolinium64Gd
terbium65Tb
dysprosium66Dy
holmium67Ho
erbium68Er
thulium69Tm
ytterbium70Yb
lutetium71Lu
hafnium72Hf
tantalum73Ta
tungsten74W
rhenium75Re
osmium76Os
iridium77Ir
platinum78Pt
gold79Au
mercury80Hg
thallium81Tl
lead82Pb
bismuth83Bi
polonium84Po
radon86Rn
radium88Ra
actinium89Ac
thorium90Th
protactinium91Pa
uranium92U
neptunium93Np
plutonium94Pu
americium95Am
curium96Cm
berkelium97Bk
californium98Cf
einsteinium99Es

Other wavelengths

Without qualification, "spectral lines" generally implies that one is talking about lines with wavelengths which fall into the range of the visible spectrum.

However, there are also many spectral lines which show up at wavelengths outside this range.

At the much shorter wavelengths of x-rays, these are known as characteristic X-rays. Other frequencies have atomic spectral lines as well, such as the Lyman series, which falls in the ultraviolet range.
