MAN Truck & Bus AG (formerly MAN Nutzfahrzeuge AG, pronounced [ˈman ˈnʊtsˌfaːɐ̯tsɔʏɡə ʔaːˈɡeː]) is the largest subsidiary of the MAN SE corporation, and one of the leading international providers of commercial vehicles. Headquartered in Munich, Germany, MAN Truck & Bus produces vans in the range from 3.0 to 5.5 t gvw, trucks in the range from 7.49 to 44 t gvw, heavy goods vehicles up to 250 t road train gvw, bus-chassis, coaches, interurban coaches, and city buses. MAN Truck & Bus also produces diesel and natural-gas engines. The MAN acronym originally stood for Maschinenfabrik Augsburg-Nürnberg AG (pronounced [maˈʃiːnənfaˌbʁiːk ˈʔaʊksbʊʁk ˈnʏʁnbɛʁk; -faˌbʁɪk-]), formerly MAN AG.
On 1 January 2011, MAN Nutzfahrzeuge (literally: commercial vehicles) was renamed as MAN Truck & Bus to better reflect the company's products on the international market.[6]
History
Light truck collaborations with Saviem and Volkswagen
From 1967 until 1977, MAN collaborated with France's Saviem, selling their light to medium duty trucks with MAN badging in Germany and certain other markets. After the end of this, a deal was struck with Volkswagen which lasted until 1993. Production of a truck using the Volkswagen LT body started in 1979 and ended in 1993 with 72,000 units produced. It was available with four engines and four wheelbases over its lifetime; there was also a 4X4 version called 8.150 FAE. FAE means "forward control" cab, all-wheel drive, single tyres so the F nomenclature means "forward control" cab. This series is usually referred to as the G90, from the most common model, but also as the "G"-series. In the United Kingdom it was originally marketed as the "MAN MT" series. The original lineup in the UK consisted of the 6.90 and the 8.90 (the first digit denoting the GVW in tonnes, the second for power in metric horsepower) and the 8.136 and 9.136.[7]
MAN AG supplied engines which were available in inline-four and inline-six cylinder engine configurations, with DIN rated motive power outputs of:
67 kilowatts (91 PS; 90 bhp)
75 kilowatts (102 PS; 101 bhp)
101 kilowatts (137 PS; 135 bhp)
112 kilowatts (152 PS; 150 bhp)
MAN replaced the G series with the L2000 and M2000 ranges. Several models of the MAN-VWCV and the VWCV LT ranges were marketed in Spain by Enasa as Pegaso Ekus, in a typical badge engineering operation. Peterbilt also offered this model with their badging, as the 200 or 265 model.
VWCV and MAN shared the project development in accordance with the collaboration agreement as follows:
Volkswagen Commercial Vehicles took care of:
the tilting driver's cab including steering wheel and fixing, hand levers and foot pedals.[1]cabins so they can fit the truck chassis
the complete interior equipment and heating
the manual gearbox with clutch and gear lever, the rear axle with rear-axle transmission and suspension
the Cardan shafts including bearings
the electrical system for the entire concept, and the platforms for the standard design.
MAN was responsible for:
the engine including cooling, exhaust, inlet and fuel system
the front axle with suspension and steering
the frame with all parts for attaching the springs and axles, the steering, the batteries, the power braking system and fuel system
the brakes, i.e. for the complete wheel brakes front and rear, the dual-circuit power brakes and parking brake
the wheels and tyres
the platform for special designs and tipping mechanism.
MAN-VWCVs were built in Volkswagen's Hanover factory until other Volkswagen models took priority; they were then made at MAN AG's Salzgitter-Watenstedt factory.
MAN-VWCV Range 6.90, 8.90, 6.100, 8.136, 8.100, 8.150, 9.136, 9.150 & 10.136.[2]
Trucks
Commercial trucks
LE / L2000
ME / M2000
FE / F2000
CLA
TGL, with hybrid trucks (MAN TGL Optistrang and TGL EDA).
TGM
TGA
TGX / TGS – a variant of the TGS model was used for Dakar Rally
MAN TGE - A rebadged Volkswagen Crafter.
Until 2007, MAN also built the badge-engineered ERF trucks for the UK market.
Military trucks
Rheinmetall MAN Military Vehicles, a joint venture with Rheinmetall, produces a range of tactical trucks:
HX
LX / FX
SX
Buses
Current
Lion's City, city and inter-urban buses
Lion's Coach, coaches
Lion's Intercity, inter-urban buses
Historical
MAN 750 HO.
MAN SG 220-18-2 in Seattle.
MAN NL 222.
MAN NG 313.
MAN ÜL 363-13,7.
MAN Lion's Star demonstrator.
- The first integral buses
760 UO, underfloor engine (1957–?)
MAN/Krauss-Maffei Metrobus[9] 640 HO (1959–1962) 750 HO (1962–1974)
890 UO, underfloor engine
890 UG, articulated bus, underfloor engine
535 HO, regional bus and coach
- VöV-Standardbuses, 1st generation
750 HO-SL (renamed SL 192 from 1972), city bus (1968–1973)
750 HO-SÜ (renamed SÜ 230 from 1972), regional bus (1970–1975)
890 SG (renamed SG 192 from 1972), articulated bus, underfloor engine (1970–1980)
SL 200, city bus (1973–1988)
SÜ 240, regional bus (1972–1989)
SD 200, double-decker bus (1973–1985)
SG 220, articulated bus, underfloor engine (1978–1983)
SG 240/280 H, articulated bus, rear engine (1980–1986)
North-American models: SG 220, articulated bus, underfloor engine (1978–1983) SG 310, articulated bus, underfloor engine (1981–1988)
- VöV-Standard buses, 2nd generation
SL 202, city bus (1984–1993)
SG 242/282 H, "puller" articulated bus (1985–1990)
SG 242/262/292/312/322, "pusher" articulated bus (1986–1999)
SD 202, double-decker bus (1986–1992)
SÜ 242/272/292/312/322, regional bus (1987–1998)
SM 152/182, midibus (1989–1992)
NL 202, low-floor bus with podium-mounted seats (1989–1992)
NG 272, low-floor articulated bus with podium-mounted seats (1990–1992)
NM 152/182, low-floor midibus with podium-mounted seats (1990–1993)
NL 202/222/262/312, low-floor bus with podium-mounted seats in rear part only (1992–1998) MAN NL 262 R, right-hand drive version for Hong Kong (1997–1999)
NG 262/272/312, low-floor articulated bus with podium-mounted seats in rear part only (1992–2000)
NM 152/192, low-floor midibus with podium-mounted seats in rear part only (1993–1998)
ND 202, low-floor double-decker bus (1995)
EL 202/222/262/272, low-entry bus (1993–2001)
North-American models: SL 40-102 "Americana", transit bus (1984–1988)
- Post-VöV-Standard buses
1st generation Lion's City city- / inter-urban buses (1996–2004) NÜ 223/233/263/283/313, low-floor inter-urban bus (1996–2004) NÜ 313/353-15, 14.7-metre version (1998–2004) NL 223/233/243/263/283/313, low-floor city bus (1997–2004) (also known as Lion's Line) NL 313/353-15, 14.7-metre version (1999–2004) (also known as Lion's Line XXL) NM 223/283, low-floor midibus (1997–2004) (also known as Lion's Midi and Lion's Single) NG 223/243/263/313/353/363, low-floor articulated bus (1997–2004) EL 223/263/283/293, low-entry bus (2003–2008) (also known as Lion's City T and Lion's City TÜ)
Lion's Classic city- / inter-urban buses (1999–2010) (un-named until 2004) SG 263/313, articulated bus (2001–2008) (also known as Lion's Classic G from 2004) SL 223/263/283 (2000–2010) (also known as Lion's Classic from 2004) SÜ 283/313 (1999–2009) (also known as Lion's Compact, as Lion's Classic Ü from 2004)
- Regional buses
RÜ 240/280 (1980–1988)
ÜL 242/272/292/312/322 (1990–1996) ÜM 192/222, midibus
ÜL 313/353/363 (1996–2004) R 353/363 Lion's Comfort
Lion's Regio (2004–2017)
- Coaches
SR 240/280 (1975–1984) SR 240/280 H, high-decker version (1978–1984)
SR 321/361 (?–?) SR 321/361 H, high-decker version (?–?)
SR 292/362 (renamed FR 292/362 from 1990) (1985–1993) SR 292/362 H (renamed FRH 292/362 from 1990), high-decker version (1985–1993)
Lion's Star (1991–2006, replaced by Lion's Coach Supreme) FRH 422/402 (1991–1998) RH 403/463 (1998–2001) RHS 414/464/484 (2001–2006)
1st generation Lion's Coach: RH 353/363/403/413/423/463 (1996–2003)
Chassis
Hubertia-bodied MAN MKN 630.
Optare Vecta bodied MAN 11.190 HOCL.
MCV Evolution bodied MAN NL 323 F.
MKN (1948–1950)
MKN 26 (1950–1954)
MKN 630 (1954–1956)[10]
MKH 2
MKH 4
530 HOC (1955–?)
535 HOC (1956–?)
545 HOC
558 HOC (1956–?)
420 HOC (1957–1963)[11]
10.xxx FOCL (L53) front-engined midi
10.xxx HOCL (469) midi
12.xxx HOCL-NL (A76) low-floor midi
12.xxx HOCL (A77) midi
13.xxx HOCL/SR (A53) midi
14.xxx HOCL-NL (A66) low-entry
14.xxx HOCL (A67)
16.xxx HOCL (470/475)
18.xxx HOCL-NL (A69) low-entry
18.xxx HOCL (A51/R33)
19.xxx HOCL (R33)
24.xxx HOCLN (474/A54/R37)
24.xxx HOCLNR-NL (A57/A59)
28.xxx HGOCL (A61)
EL 202 F (A17) low-entry
ND 202 F (A14) low-floor double-decker
NL 202 F (898/A29) low-floor
ND xx3 F (A34/A48/A95) low-floor double-decker
NG xx3 F (A24) articulated low-floor
NL xx3 F (A22) low-floor
NM xx3 F (A35) low-floor midi
SL 18.xxx HOC (A89)
SÜ xx3 F (A91)
Lion's Chassis low-entry, intercity and coach (modular)
Production sites
Trucks
Heavy range
Munich (GER)
Salzgitter (GER)
Kraków (POL)
Light and medium range
Steyr (A)
Special-purpose vehicles
Vienna (A)
Buses
Ankara (TUR): MANAŞ - premium coaches, standard coaches, double-decker coaches, intercity buses, city buses
Poznań (POL) - moved to Starachowice
Starachowice (POL) - city buses, bus and coach chassis, components ( in future: premium coaches, standard coaches, double-decker coaches, intercity buses)
Salzgitter (GER) - bus and coach chassis
Carmona (PH) - bus body under name of Almazora Motors Corporation
Santa Rosa (PH) - bus body under name of Santarosa Motor Works, Inc. (Columbian Manufacturing Corp.)
Quezon City (PH) - bus body under name of Del Monte Motor Works, Inc.
Engines
Nuremberg (GER)
CKD-locations
Shushary, Saint Petersburg, (RUS): Heavy-weight trucks
Pune, (IND): Heavy-weight trucks
Pinetown (RSA): heavy, medium and light trucks; bus-chassis[12]
Querétaro (MEX)
Olifantsfontein (RSA): intercity- and regular service buses[12]
Sharjah, (UAE): Assembling of truck under the Shacman brand. The company is a part of the Shaanxi Automobile Group.
East Jakarta, (IDN): Assembling of trucks and buses at a plant in Jatinegara, East Jakarta by PT. Duta Putera Sumatera.
Rawang, (MYS)
Quezon City, (PH): Assembling of trucks and buses at MAN Truck and Bus Center assembly plant in Novaliches, Quezon City by MAN Automotive Concessionaires Corporation.
Bangkok, (THA): Assembling of trucks and buses in Thailand by MAN Commercial Vehicle (Thailand) Co., Ltd.
Samarkand, (UZB): Assembling of two trucks in Uzbekistan by MAN Auto-Uzbekistan.
